Upgrade your system with precision and reliability using the T and F-Range Front-Mounted Pneumatic Timer Block.
Regular price
$129.99
Regular price
Sale price
$129.99
Unit price
per
Initiate Order
Front-Mounted Pneumatic Timer Block - T and F-Range
$129.99
Quantity: 1
Claim Your Seller Account
Front-Mounted Pneumatic Timer Block - T and F-Range
$129.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Enhance operational efficiency with this Front-Mounted Pneumatic Timer Block from Shamrock Controls. With a range of 0.1 to 30 seconds, this timer block ensures precise timing for various applications. Rated for 660V operational voltage and compliant with CSA standards, it offers reliable performance with repeated accuracy of 5%. Featuring a mechanical life of 5 million cycles and auxiliary contacts for enhanced functionality, this timer block is ideal for contactors in both consumer and institutional settings.
Product Specifications
Specifications Accuracy Only Valid For Setting Range
15 %
Specifications Auxiliary Contacts Normally Closed Nc
1
Specifications Auxiliary Contacts Normally Open No
1
Specifications Frequency Of Operational Current
25 to 400 Hz
Specifications Indicated On The Front Face Per Degree Celsius C
0.25 %
Specifications Insulation Resistance
> 10 MΩ
Specifications Mechanical Life
5 Million Cycles
Specifications Minimum Switching Current Capacity I Min
5 mA
Specifications Minimum Switching Voltage Capacity U Min
17 V
Specifications Number Of Contacts
2
Specifications Permissible Short Time Current Rating For At 100
140 A
Specifications Permissible Short Time Current Rating For At 1 Se
100 A
Specifications Permissible Short Time Current Rating For At 500
120 A
Specifications Range
0.1 to 30 s
Specifications Rated Insulation Voltage Ui Conforming To Canadia
690 V
Specifications Rated Operational Voltage Ue
660 V
Specifications Rated Thermal Current For Ambient Temperature 40
10 A
Specifications Repeat Accuracy
5 %
Specifications Time Delay Ambient Air Temperature For Operation
-40 to 70 ºC
