FS Curtis CW 100HP Two Stage Industrial Air Compressor
FS Curtis CW 100HP Two Stage Industrial Air Compressor
SKU:FSC-68e8a5
Powerful 100HP industrial air compressor with premium efficiency and safety features. Meets CAGI, ISO standards. Enhance productivity and reliability.
Regular price
$24,999.99
Regular price
Sale price
$24,999.99
Unit price
per
Initiate Order
FS Curtis CW 100HP Two Stage Industrial Air Compressor
$24,999.99
Quantity: 1
Claim Your Seller Account
FS Curtis CW 100HP Two Stage Industrial Air Compressor
$24,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 100HP Two Stage Industrial Reciprocating Air Compressor is a powerhouse designed for heavy-duty industrial applications. Featuring a 100hp motor power, it delivers a remarkable flow capacity of up to 345 ft³/min at 200 psi. This compressor is equipped with premium efficient ODP motor, large metal intake filter silencers, and OSHA-approved enclosed belt guard for enhanced safety. Meeting industry standards like CAGI, ISO 14001, and ISO 9001, this compressor ensures reliability and efficiency in compressed air systems. Continuous improvements by FS Curtis guarantee top-notch performance.
Product Specifications
Large Industrial Dimensions And Weights Height
75 in
Large Industrial Dimensions And Weights Length
92 in
Large Industrial Dimensions And Weights Net Weight
3700 lb
Large Industrial Dimensions And Weights Width
57 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 200 Psi Rating
345 ft³/min
Specifications Flow Capacity At 250 Psi Rating
317 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
100 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 200 Psi Rating
657 rpm
Specifications Speed At 250 Psi Rating
618 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
