FS Curtis CW Series 100 HP Two Stage Industrial Air Compressor
FS Curtis CW Series 100 HP Two Stage Industrial Air Compressor
SKU:FSC-05056f
Powerful 100 HP Two Stage Industrial Air Compressor by FS Curtis, industry-standard compliant for reliable performance.
Regular price
$11,500.00
Regular price
Sale price
$11,500.00
Unit price
per
Initiate Order
FS Curtis CW Series 100 HP Two Stage Industrial Air Compressor
$11,500.00
Quantity: 1
Claim Your Seller Account
FS Curtis CW Series 100 HP Two Stage Industrial Air Compressor
$11,500.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 100 HP Two Stage Industrial Air Compressor is a powerhouse designed for industrial applications, delivering a flow capacity of up to 482 ft³/min at 100 psi. With premium efficient ODP motor and constant speed control, it ensures reliable performance. Equipped with OSHA-approved safety features and optional add-ons like the auto start/stop control, this compressor offers efficiency with peace of mind. Meeting industry standards such as CAGI, ISO 14001, and ISO 9001, it exemplifies FS Curtis' commitment to quality and innovation.
Product Specifications
Large Industrial Dimensions And Weights Height
75 in
Large Industrial Dimensions And Weights Length
92 in
Large Industrial Dimensions And Weights Net Weight
3700 lb
Large Industrial Dimensions And Weights Width
57 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 100 Psi Rating
482 ft³/min
Specifications Flow Capacity At 125 Psi Rating
438 ft³/min
Specifications Flow Capacity At 150 Psi Rating
413 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
100 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 100 Psi Rating
583 rpm
Specifications Speed At 125 Psi Rating
775 rpm
Specifications Speed At 150 Psi Rating
735 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
