FS Curtis CW Series 100HP Single Stage Air Compressor
FS Curtis CW Series 100HP Single Stage Air Compressor
SKU:FSC-18215b
Powerful 100HP industrial air compressor meeting highest standards, reliable performance, and safety features.
Regular price
$14,999.99
Regular price
Sale price
$14,999.99
Unit price
per
Initiate Order
FS Curtis CW Series 100HP Single Stage Air Compressor
$14,999.99
Quantity: 1
Claim Your Seller Account
FS Curtis CW Series 100HP Single Stage Air Compressor
$14,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 100HP Single Stage Industrial Reciprocating Air Compressor is a powerhouse designed for high-performance industrial applications. With a motor power of 100 horsepower and flow capacities ranging from 530 to 676 ft³/min at various psi ratings, this compressor delivers consistent and reliable compressed air. It meets industry standards such as CAGI, ISO 14001, and ISO 9001, ensuring quality and efficiency. Featuring OSHA-approved safety features, pressure lubrication systems, and optional accessories like auto start/stop control, this compressor is versatile and user-friendly. Trust FS Curtis for top-notch air compressors that exceed expectations.
Product Specifications
Large Industrial Dimensions And Weights Height
75 in
Large Industrial Dimensions And Weights Length
92 in
Large Industrial Dimensions And Weights Net Weight
3700 lb
Large Industrial Dimensions And Weights Width
57 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 40 Psi Rating
676 ft³/min
Specifications Flow Capacity At 50 Psi Rating
642 ft³/min
Specifications Flow Capacity At 60 Psi Rating
593 ft³/min
Specifications Flow Capacity At 70 Psi Rating
530 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
100 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 40 Psi Rating
814 rpm
Specifications Speed At 50 Psi Rating
800 rpm
Specifications Speed At 60 Psi Rating
760 rpm
Specifications Speed At 70 Psi Rating
696 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
