FS Curtis CW Series 125 HP Two Stage Air Compressor
FS Curtis CW Series 125 HP Two Stage Air Compressor
SKU:FSC-90e4cc
Powerful FS Curtis CW Series 125 HP Air Compressor with premium features for industrial use. Meets CAGI, ISO standards. Continuous improvements for peak performance.
Regular price
$8,499.99
Regular price
Sale price
$8,499.99
Unit price
per
Initiate Order
FS Curtis CW Series 125 HP Two Stage Air Compressor
$8,499.99
Quantity: 1
Claim Your Seller Account
FS Curtis CW Series 125 HP Two Stage Air Compressor
$8,499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 125 HP Two Stage Industrial Reciprocating Air Compressor is a powerhouse designed for industrial applications. With a 125 hp motor power and impressive flow capacity at various psi ratings, this compressor ensures efficient and reliable operation. Equipped with premium features like OSHA-approved belt guard, Centro-ring™ oil system, and optional controls for enhanced functionality, it meets the high standards set by CAGI, ISO 14001, and ISO 9001. Continuous improvements by FS Curtis guarantee cutting-edge performance. Invest in this compressor for superior air compression needs.
Product Specifications
Large Industrial Dimensions And Weights Height
75 in
Large Industrial Dimensions And Weights Length
92 in
Large Industrial Dimensions And Weights Net Weight
3950 lb
Large Industrial Dimensions And Weights Width
57 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 100 Psi Rating
505 ft³/min
Specifications Flow Capacity At 125 Psi Rating
491 ft³/min
Specifications Flow Capacity At 150 Psi Rating
475 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
125 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 100 Psi Rating
931 rpm
Specifications Speed At 125 Psi Rating
891 rpm
Specifications Speed At 150 Psi Rating
853 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
