The FS Curtis CW Series 125 HP Two Stage Industrial Reciprocating Air Compressor is a powerhouse designed for industrial applications. With a motor power of 125 HP, it delivers a flow capacity of up to 437 ft³/min at 200 psi. This compressor meets industry standards like CAGI, ISO 14001, and ISO 9001. Equipped with premium features such as a large metal intake filter silencer, OSHA-approved enclosed belt guard, and Centro-ring™ oil system, it ensures efficient and reliable operation. Optional upgrades include auto start/stop control and NEMA-4 control panel enclosure for enhanced functionality and convenience.
Product Specifications
Large Industrial Dimensions And Weights Height
75 in
Large Industrial Dimensions And Weights Length
92 in
Large Industrial Dimensions And Weights Net Weight
3950 lb
Large Industrial Dimensions And Weights Width
57 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 200 Psi Rating
437 ft³/min
Specifications Flow Capacity At 250 Psi Rating
406 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
125 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 200 Psi Rating
811 rpm
Specifications Speed At 250 Psi Rating
772 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
