The FS Curtis CW Series 30 HP Motor Power Two Stage Industrial Reciprocating Air Compressor is a powerhouse designed for industrial applications. With a premium efficient ODP motor and constant speed control, this compressor delivers reliable performance. Equipped with large metal intake filter silencers and meeting industry standards such as CAGI, ISO 14001, and ISO 9001, it ensures efficiency and compliance with quality regulations. Optional features like auto start/stop control and NEMA-4 control panel enclosure enhance functionality for your specific needs.
Product Specifications
Large Industrial Dimensions And Weights Height
46.5 in
Large Industrial Dimensions And Weights Length
80.5 in
Large Industrial Dimensions And Weights Net Weight
1750 lb
Large Industrial Dimensions And Weights Width
44.5 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 100 Psi Rating
137 ft³/min
Specifications Flow Capacity At 125 Psi Rating
128 ft³/min
Specifications Flow Capacity At 150 Psi Rating
120 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
30 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 100 Psi Rating
654 rpm
Specifications Speed At 125 Psi Rating
617 rpm
Specifications Speed At 150 Psi Rating
580 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
