FS Curtis CW Series 30HP Single Stage Industrial Air Compressor
FS Curtis CW Series 30HP Single Stage Industrial Air Compressor
SKU:FSC-2588bb
Powerful 30HP single-stage industrial air compressor with premium features and industry-standard compliance.
Regular price
$7,899.99
Regular price
Sale price
$7,899.99
Unit price
per
Initiate Order
FS Curtis CW Series 30HP Single Stage Industrial Air Compressor
$7,899.99
Quantity: 1
Claim Your Seller Account
FS Curtis CW Series 30HP Single Stage Industrial Air Compressor
$7,899.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 30HP Single Stage Industrial Air Compressor is a powerhouse designed for industrial applications. With a motor power of 30 hp and flow capacities ranging from 146 to 222 ft³/min at different psi ratings, it offers reliable performance. This compressor meets CAGI, ISO 14001, and ISO 9001 standards, ensuring quality and efficiency for continuous operation. Equipped with premium features like an enclosed belt guard, Centro-ring™ oil system, and optional auto start/stop control, this compressor delivers superior functionality and durability.
Product Specifications
Large Industrial Dimensions And Weights Height
46.5 in
Large Industrial Dimensions And Weights Length
80.5 in
Large Industrial Dimensions And Weights Net Weight
1750 lb
Large Industrial Dimensions And Weights Width
44.5 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 30 Psi Rating
222 ft³/min
Specifications Flow Capacity At 40 Psi Rating
203 ft³/min
Specifications Flow Capacity At 50 Psi Rating
184 ft³/min
Specifications Flow Capacity At 60 Psi Rating
166 ft³/min
Specifications Flow Capacity At 70 Psi Rating
146 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
30 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 30 Psi Rating
850 rpm
Specifications Speed At 40 Psi Rating
800 rpm
Specifications Speed At 50 Psi Rating
770 rpm
Specifications Speed At 60 Psi Rating
735 rpm
Specifications Speed At 70 Psi Rating
690 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
