FS Curtis CW Series 40hp two-stage Industrial Air Compressor
FS Curtis CW Series 40hp two-stage Industrial Air Compressor
SKU:FSC-050b26
Powerful 40hp two-stage industrial air compressor with premium efficient ODP motor, consistent speed control, and flow capacity up to 172 ft³/min at 100 psi.
Regular price
$7,999.00
Regular price
Sale price
$7,999.00
Unit price
per
Initiate Order
FS Curtis CW Series 40hp two-stage Industrial Air Compressor
$7,999.00
Quantity: 1
Claim Your Seller Account
FS Curtis CW Series 40hp two-stage Industrial Air Compressor
$7,999.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 40 Horsepower Two Stage Industrial Reciprocating Air Compressor is a powerful and reliable solution for industrial air compression needs. With a premium efficient ODP motor and constant speed control, this compressor delivers a flow capacity of up to 172 ft³/min at 100 psi. Equipped with large metal intake filter silencers and meeting industry standards including CAGI, ISO 14001, and ISO 9001, it ensures top-notch performance and durability. Optional features like auto start/stop control and NEMA-4 control panel enclosure enhance usability for diverse operational requirements.
Product Specifications
Large Industrial Dimensions And Weights Height
46.5 in
Large Industrial Dimensions And Weights Length
80.5 in
Large Industrial Dimensions And Weights Net Weight
1950 lb
Large Industrial Dimensions And Weights Width
44.5 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 100 Psi Rating
172 ft³/min
Specifications Flow Capacity At 125 Psi Rating
165 ft³/min
Specifications Flow Capacity At 150 Psi Rating
149 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
40 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 100 Psi Rating
837 rpm
Specifications Speed At 125 Psi Rating
800 rpm
Specifications Speed At 150 Psi Rating
727 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
