FS Curtis CW Series 50 HP Two Stage Industrial Air Compressor
FS Curtis CW Series 50 HP Two Stage Industrial Air Compressor
SKU:FSC-4c7c1b
Powerful 50 HP Two Stage Air Compressor for industrial applications. Premium efficiency and industry-standard compliant.
Regular price
$8,999.99
Regular price
Sale price
$8,999.99
Unit price
per
Initiate Order
FS Curtis CW Series 50 HP Two Stage Industrial Air Compressor
$8,999.99
Quantity: 1
Claim Your Seller Account
FS Curtis CW Series 50 HP Two Stage Industrial Air Compressor
$8,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 50 HP Two Stage Industrial Air Compressor is a powerhouse designed for industrial applications, offering a motor power of 50 hp and a flow capacity of up to 240 ft³/min. With premium efficient ODP motor and constant speed control, this compressor ensures reliable performance. Equipped with large metal intake filter silencers and meeting industry standards such as CAGI, ISO 14001, and ISO 9001, this compressor is ideal for demanding work environments. Optional equipment includes auto start/stop control and TEFC motor for enhanced functionality.
Product Specifications
Large Industrial Dimensions And Weights Height
53 in
Large Industrial Dimensions And Weights Length
82 in
Large Industrial Dimensions And Weights Net Weight
2720 lb
Large Industrial Dimensions And Weights Width
42.5 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 100 Psi Rating
240 ft³/min
Specifications Flow Capacity At 125 Psi Rating
219 ft³/min
Specifications Flow Capacity At 150 Psi Rating
206 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
50 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 100 Psi Rating
850 rpm
Specifications Speed At 125 Psi Rating
772 rpm
Specifications Speed At 150 Psi Rating
733 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
