FS Curtis CW Series 50HP Single Stage Industrial Air Compressor
FS Curtis CW Series 50HP Single Stage Industrial Air Compressor
SKU:FSC-c223eb
Powerful FS Curtis CW Series 50HP Industrial Air Compressor for efficient industrial applications.
Regular price
$10,999.00
Regular price
Sale price
$10,999.00
Unit price
per
Initiate Order
FS Curtis CW Series 50HP Single Stage Industrial Air Compressor
$10,999.00
Quantity: 1
Claim Your Seller Account
FS Curtis CW Series 50HP Single Stage Industrial Air Compressor
$10,999.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 50HP Single Stage Industrial Air Compressor is a powerhouse designed for industrial applications. With a robust 50 horsepower motor, it delivers a flow capacity of up to 400 ft³/min at 30 psi, meeting the demanding needs of industrial settings. Equipped with premium efficient ODP motor, V-belt drive, and large metal intake filter silencers, this compressor ensures reliable and efficient performance. Compliant with CAGI Compressed Air and Gas Institute®, ISO 14001, and ISO 9001 standards, it guarantees quality and reliability for your operations.
Product Specifications
Large Industrial Dimensions And Weights Height
53 in
Large Industrial Dimensions And Weights Length
82 in
Large Industrial Dimensions And Weights Net Weight
2720 lb
Large Industrial Dimensions And Weights Width
42.5 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 30 Psi Rating
400 ft³/min
Specifications Flow Capacity At 40 Psi Rating
346 ft³/min
Specifications Flow Capacity At 50 Psi Rating
330 ft³/min
Specifications Flow Capacity At 60 Psi Rating
303 ft³/min
Specifications Flow Capacity At 70 Psi Rating
267 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
50 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 30 Psi Rating
950 rpm
Specifications Speed At 40 Psi Rating
850 rpm
Specifications Speed At 50 Psi Rating
835 rpm
Specifications Speed At 60 Psi Rating
800 rpm
Specifications Speed At 70 Psi Rating
733 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
