FS Curtis CW Series 50HP Two Stage Industrial Air Compressor
FS Curtis CW Series 50HP Two Stage Industrial Air Compressor
SKU:FSC-13fecf
Powerful 50HP air compressor with premium features and industry standards compliance.
Regular price
$8,999.99
Regular price
Sale price
$8,999.99
Unit price
per
Initiate Order
FS Curtis CW Series 50HP Two Stage Industrial Air Compressor
$8,999.99
Quantity: 1
Claim Your Seller Account
FS Curtis CW Series 50HP Two Stage Industrial Air Compressor
$8,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 50HP Two Stage Industrial Air Compressor is a powerhouse designed for demanding industrial applications. With a robust 50 horsepower motor and premium efficient ODP motor, it delivers a flow capacity of 154 ft³/min at 200 psi. Equipped with industry-leading features like a large metal intake filter silencer and constant speed control, this compressor ensures reliable performance and efficiency. Meeting industry standards such as CAGI, ISO 14001, and ISO 9001, this compressor is a top choice for institutions seeking quality and reliability in their compressed air systems.
Product Specifications
Large Industrial Dimensions And Weights Height
53 in
Large Industrial Dimensions And Weights Length
82 in
Large Industrial Dimensions And Weights Net Weight
2700 lb
Large Industrial Dimensions And Weights Width
42.5 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 200 Psi Rating
154 ft³/min
Specifications Flow Capacity At 250 Psi Rating
146 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
50 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 200 Psi Rating
840 rpm
Specifications Speed At 250 Psi Rating
803 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
