FS Curtis CW Series 60HP Single Stage Industrial Air Compressor
FS Curtis CW Series 60HP Single Stage Industrial Air Compressor
SKU:FSC-65c4d6
Powerful FS Curtis CW Series 60HP Industrial Air Compressor with premium features for reliable performance.
Regular price
$8,999.99
Regular price
Sale price
$8,999.99
Unit price
per
Initiate Order
FS Curtis CW Series 60HP Single Stage Industrial Air Compressor
$8,999.99
Quantity: 1
Claim Your Seller Account
FS Curtis CW Series 60HP Single Stage Industrial Air Compressor
$8,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 60HP Single Stage Industrial Air Compressor is a powerhouse designed for industrial applications. With a motor power of 60 horsepower and precise speed and flow capacity ratings at different pressure levels, this compressor ensures consistent performance. It features a premium efficient motor, large metal intake filter silencers, and a V-belt drive for reliability. Meeting industry standards like CAGI, ISO 14001, and ISO 9001, this compressor is a reliable choice for continuous operations. Optional equipment includes auto start/stop control and high-temperature shutdown features, enhancing safety and efficiency.
Product Specifications
Large Industrial Dimensions And Weights Height
53 in
Large Industrial Dimensions And Weights Length
82 in
Large Industrial Dimensions And Weights Net Weight
3000 lb
Large Industrial Dimensions And Weights Width
42.5 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 40 Psi Rating
302 ft³/min
Specifications Flow Capacity At 50 Psi Rating
373 ft³/min
Specifications Flow Capacity At 60 Psi Rating
333 ft³/min
Specifications Flow Capacity At 70 Psi Rating
297 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
60 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 40 Psi Rating
811 rpm
Specifications Speed At 50 Psi Rating
950 rpm
Specifications Speed At 60 Psi Rating
875 rpm
Specifications Speed At 70 Psi Rating
811 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
