FS Curtis CW Series 60HP Two Stage Industrial Air Compressor
FS Curtis CW Series 60HP Two Stage Industrial Air Compressor
SKU:FSC-4c665c
Powerful and reliable 60HP industrial air compressor with premium features for heavy-duty applications.
Regular price
$8,999.99
Regular price
Sale price
$8,999.99
Unit price
per
Initiate Order
FS Curtis CW Series 60HP Two Stage Industrial Air Compressor
$8,999.99
Quantity: 1
Claim Your Seller Account
FS Curtis CW Series 60HP Two Stage Industrial Air Compressor
$8,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 60HP Two Stage Industrial Air Compressor is a powerhouse designed for heavy-duty industrial applications. With a motor power of 60 hp and flow capacities ranging from 237 to 259 ft³/min at various pressure ratings, this compressor delivers consistent and reliable performance. It comes with premium efficient ODP motor, V-belt drive system, and metal intake filter silencers for efficient operation and reduced noise levels. Equipped with standard features like OSHA-approved enclosed belt guard and Centro-ring™ oil system, this compressor ensures safe and smooth operation. Optional equipment such as auto start/stop control and TEFC motor add versatility and convenience to meet specific operational needs. Proudly meeting industry standards including CAGI, ISO 14001, and ISO 9001, the FS Curtis CW Series guarantees quality and performance excellence for every application.
Product Specifications
Large Industrial Dimensions And Weights Height
53 in
Large Industrial Dimensions And Weights Length
82 in
Large Industrial Dimensions And Weights Net Weight
3000 lb
Large Industrial Dimensions And Weights Width
42.5 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 100 Psi Rating
259 ft³/min
Specifications Flow Capacity At 125 Psi Rating
248 ft³/min
Specifications Flow Capacity At 150 Psi Rating
237 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
60 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 100 Psi Rating
928 rpm
Specifications Speed At 125 Psi Rating
889 rpm
Specifications Speed At 150 Psi Rating
850 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
