FS Curtis CW Series 75 HP Industrial Air Compressor
FS Curtis CW Series 75 HP Industrial Air Compressor
SKU:FSC-7f37cc
Powerful and reliable 75 HP industrial air compressor with premium efficient motor, constant speed control, and large intake filter silencer.
Regular price
$12,999.00
Regular price
Sale price
$12,999.00
Unit price
per
Initiate Order
FS Curtis CW Series 75 HP Industrial Air Compressor
$12,999.00
Quantity: 1
Claim Your Seller Account
FS Curtis CW Series 75 HP Industrial Air Compressor
$12,999.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 75 HP Single Stage Industrial Reciprocating Air Compressor packs power and reliability for industrial applications. With a premium efficient ODP motor and constant speed control, it delivers a flow capacity of up to 565 ft³/min at 40 psi rating. Equipped with a large metal intake filter silencer and meeting industry standards like ISO 14001 and ISO 9001, this compressor is built to optimize performance and durability. Optional equipment includes auto start/stop control and NEMA-4 control panel enclosure for enhanced control and safety.
Product Specifications
Large Industrial Dimensions And Weights Height
75 in
Large Industrial Dimensions And Weights Length
92 in
Large Industrial Dimensions And Weights Net Weight
3500 lb
Large Industrial Dimensions And Weights Width
57 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 40 Psi Rating
565 ft³/min
Specifications Flow Capacity At 50 Psi Rating
512 ft³/min
Specifications Flow Capacity At 60 Psi Rating
496 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
75 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 40 Psi Rating
955 rpm
Specifications Speed At 50 Psi Rating
640 rpm
Specifications Speed At 60 Psi Rating
640 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
