FS Curtis CW Series 75 HP Two Stage Industrial Air Compressor
FS Curtis CW Series 75 HP Two Stage Industrial Air Compressor
SKU:FSC-17fe4a
Powerful 75 HP Two Stage Industrial Air Compressor with premium efficiency and safety features.
Regular price
$8,499.99
Regular price
Sale price
$8,499.99
Unit price
per
Initiate Order
FS Curtis CW Series 75 HP Two Stage Industrial Air Compressor
$8,499.99
Quantity: 1
Claim Your Seller Account
FS Curtis CW Series 75 HP Two Stage Industrial Air Compressor
$8,499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The FS Curtis CW Series 75 HP Two Stage Industrial Air Compressor is a powerhouse designed for industrial applications, offering premium efficiency and reliable performance. With a motor power of 75 hp and impressive flow capacities at various psi ratings, this compressor ensures consistent operation. It comes with standard equipment including OSHA-approved safety features and optional equipment like auto start/stop control for enhanced functionality. Measuring 92" in length, 57" in width, and 75" in height, with a net weight of 3500 lb, this compressor is built for durability and efficiency. Compliant with CAGI, ISO 14001, and ISO 9001 standards, it meets the highest industry benchmarks.
Product Specifications
Large Industrial Dimensions And Weights Height
75 in
Large Industrial Dimensions And Weights Length
92 in
Large Industrial Dimensions And Weights Net Weight
3500 lb
Large Industrial Dimensions And Weights Width
57 in
Optional Equipment 0
Auto start/stop controlDual controlLow oil shutdown on C-100 and C-150 modelsNEMA-1 high discharge air temperature shutdownNEMA-1 high interstage air temperature shutdownNEMA-4 control panel enclosureTEFC motor
Specifications Brand
FS Curtis
Specifications Flow Capacity At 100 Psi Rating
363 ft³/min
Specifications Flow Capacity At 125 Psi Rating
321 ft³/min
Specifications Flow Capacity At 150 Psi Rating
303 ft³/min
Specifications Industry Standards
CAGI Compressed Air and Gas Institute® | ISO 14001 | ISO 9001
Specifications Motor Power
75 hp
Specifications Note
Improvements and research are continuous at FS Curtis. Specifications may change without notice.
Specifications Speed At 100 Psi Rating
694 rpm
Specifications Speed At 125 Psi Rating
577 rpm
Specifications Speed At 150 Psi Rating
577 rpm
Standard Equipment 0
OSHA-approved enclosed belt guardC-100 and C-150 - Pressure lubricated with Centro-ring™ oil systemC-200, C-260 and C-300 - Pressure lubricated with gear type oil pump to include full flow oil filter, oil pressure gauge and low oil pressure shutdown switch
