G-9 Glass Melamine Rod
G-9 Glass Melamine Rod
SKU:SHA-cc1a61
High-strength G-9 Glass Melamine Rod, ground from sheet material, ideal for mechanical and electrical applications, meets MIL-I-24768/1 GME standards.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
G-9 Glass Melamine Rod
$39.99
Quantity: 1
Claim Your Seller Account
G-9 Glass Melamine Rod
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The G-9 Glass Melamine Rod, ground from sheet material, meets MIL-I-24768/1 Type GME standards. This industrial-grade thermoset composite offers exceptional dimensional stability, high hardness, and superior tensile, flexural, and compressive strengths. With a maximum operating temperature of 300°F and V0 flammability rating, this rod is ideal for various mechanical and electrical applications requiring strong, resilient, and arc-resistant materials. Easy to fabricate and machine, the G-9 Glass Melamine Rod is a top choice for support components in demanding environments.
Product Specifications
Specifications Coefficient Of Thermal Expansion Crosswise
1.0 x 10-5 in/in/ºF
Specifications Coefficient Of Thermal Expansion Lengthwise
0.83 x 10-5 in/in/ºF
Specifications Compressive Strength
70000 psi
Specifications Density Astm D792
1.95 g/cm³
Specifications Dielectric Strength Short Time 0125 Astm D149
550 V/mil
Specifications Flammability Rating Ul 94
V0
Specifications Flexural Modulus Crosswise Astm D790
13 x 105 psi
Specifications Flexural Modulus Lengthwise Astm D790
16 x 105 psi
Specifications Flexural Strength Crosswise Astm D790
58000 psi
Specifications Flexural Strength Lengthwise Astm D790
82000 psi
Specifications Hardness Rockwell Astm D785
M120
Specifications Izod Impact Strength Notched Crosswise Astm D256
9 ft·lb/in
Specifications Izod Impact Strength Notched Lengthwise Astm D256
16 ft·lb/in
Specifications Length
4 ft
Specifications Maximum Operating Temperature
300 ºF
Specifications Tensile Strength Crosswise Astm D638
32000 psi
Specifications Tensile Strength Lengthwise Astm D638
41000 psi
Specifications Tolerance
± 0.001 in
Specifications Water Absorption 24 Hrs At 0125 Astm D570
0.28 %
