Gardner Denver L-Series 75 HP Fixed-Speed Rotary Screw Compressor
Gardner Denver L-Series 75 HP Fixed-Speed Rotary Screw Compressor
SKU:ROT-b4a676
Get high-quality, efficient compressed air with the Gardner Denver L-Series 75 HP Fixed-Speed Rotary Screw Compressor. Enhanced reliability and serviceability for optimal performance.
Regular price
$16,999.99
Regular price
Sale price
$16,999.99
Unit price
per
Initiate Order
Gardner Denver L-Series 75 HP Fixed-Speed Rotary Screw Compressor
$16,999.99
Quantity: 1
Claim Your Seller Account
Gardner Denver L-Series 75 HP Fixed-Speed Rotary Screw Compressor
$16,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience unparalleled performance and serviceability with the Gardner Denver L-Series 75 HP Fixed-Speed Rotary Screw Compressor. Designed for efficiency and reliability, this compressor delivers consistent, high-quality compressed air. Its compact design saves space, reduces installation costs, and ensures near-silent operation, making it an ideal choice for manufacturers and operators seeking value and performance. With features like the Governor™ Touchscreen Controller and Total System Protection, this compressor offers advanced functionality and long-term reliability.
Product Specifications
Additional Information
The Total PackageGardner Denver™ has the total package-extensive compressor and air treatment product lines, sales and service support through our extensive network of authorized local distributors, and industry leading warranty programs. Because we offer more than just compressed air equipment, we can provide solutions that keep you running, protect your production objectives, and save you money.Get in Touch with the Next Generation of Compressor ControllersState-of-the-ArtGardner Denver™ completes its industry leading compressor packages with state-of-the-art touchscreen controllers: the GD Pilot and Governor™. Featuring cutting edge graphics that provide necessary compressor data and full color schematics in seconds, the Governor™ is now available on select L-Series compressors models.
Compact Design
Compact, Quiet CompressorsNearly Silent Noise LevelsThe Gardner Denver™ L-Series compressor designs feature high-quality, sound-insulating enclosure panels and a low-noise, thermostatically controlled, motor-driven fan. These components reduce the noise to whisper-quiet levels and eliminate the need for a separate compressor room, saving money on installation costs.
Dimensions Height
78 in | 1971 mm
Dimensions Length
85 in | 2159 mm
Dimensions Width
49 in | 1222 mm
Features
Without sacrificing serviceability, the L-Series compressor packages feature some of the smallest footprints in the industry.Lower Installation CostsIncreased Flexibility when Determining Installation LocationAbility to More Easily Handle and Move Machines
Gd Pilot Controller Features
Real time clockSecond pressure settingDischarge/line/network pressure data displayedAdvanced fault history logProgrammable inputs and outputsAuto restart after power failureRS485-Modbus RTU standard
Governor Touchscreen Controller Features
Available on L15-L290 compressor modelsUser-friendly navigation with state-of-the-art graphics and designMachine status available on a 7-inch, full color touchscreen display for L30-L290 and a 4.3-inch display for L15-L29Detailed schematics at your fingertipsAdvanced machine diagnosticsData logging and iConn connectionWeb server to allow access to the Governor™ from your desktop
Reliability
Verified PerformanceAs a member of the Compressed Air and Gas Institute's performance verification program, you can rest assured that the performance numbers that Gardner Denver™ publishes are consistent with the actual performance of our machines. Gardner Denver™ compressors, just as all lubricated rotary screw compressors 5 HP and above, are third-party tested to ensure that our performance numbers are accurate, easy-to-understand and verified.
Specifications Drive Motor Power
75 hp | 55 kW
Specifications Free Air Delivery Fad At 100 Bar Nominal Pressure
335.8 acfm | 9.5 m³/min
Specifications Free Air Delivery Fad At 131 Bar Nominal Pressure
278.0 acfm | 7.87 m³/min
Specifications Free Air Delivery Fad At 76 Bar Nominal Pressure
345.2 acfm | 9.77 m³/min
Specifications Free Air Delivery Fad At 86 Bar Nominal Pressure
343.9 acfm | 9.74 m³/min
Specifications Noise Level
73 dBA
Specifications Nominal Pressure At 50 Hertz Hz Frequency
110 psig | 145 psig | 190 psig | 7.6 bar | 10.0 bar | 13.1 bar
Specifications Nominal Pressure At 60 Hertz Hz Frequency
110 psig | 125 psig | 190 psig | 7.6 bar | 8.6 bar | 13.1 bar
Specifications Note For 69 To 131 Bar Nominal Pressure And 60 He
Data measured and stated in accordance with ISO1217, Ed. 4, Annex C & Annex E at the following conditions:Air Intake Pressure 1 bar A, Air Intake Temperature 20ºC, Humidity 0% (Dry).
Specifications Weight
3756 lb | 1704 kg
Total System Protection
Ensure your compressed air system remains a total packageSince 1859, Gardner Denver™ has been supporting the compressed air industry with high quality, long-lasting compressor and air treatment solutions. Carrying on that legacy, our robust line of parts, lubricant and downstream accessories ensure your system stays healthy.The focus on total system protection by Gardner Denver™ not only includes OEM parts and fluid solutions, but a commitment to the longevity of your equipment through our industry leading warranty programs.Protect your investment.
Warranty
The engineering philosophy of Gardner Denver™ is to design high quality, reliable equipment and help you protect your new equipment to give you peace of mind. We offer a good, better, and best approach to warranty programs.Standard WarrantyProtects your newly purchased equipment if you encounter defects in materials or workmanship for 1 year and provides 2 years of parts and labor coverage for most major components.Platinum 10-Year Extended WarrantyThe Platinum 10-Year Extended Warranty covers everything in the Standard Warranty as well as defects in materials or workmanship of the airend parts for 10 years and provides 5 years coverage on major components. The equipment must be maintained on-schedule in accordance with the requirements of the warranty statement and the operations manual.Platinum+ Full Package WarrantyAdds to the coverage of the Platinum 10-Year Extended Warranty and changes to a 5-year renewable service agreement with one of our factory trained distributors. By paying for the additional protection, you gain peace of mind, a partnership with your trusted distributor, and the added coverage of wear items and other package components.
What Is Important
Compressors are more than just a financial investment. They are a key component in ensuring that you, as a manufacturer, processor and operator, receive consistent, high-quality low-cost air. Gardner Denver™ uses the latest design techniques to develop a compressor that focuses on the three most important aspects of a compressor.ReliabilityPerformanceValue
