The Multilift Comfort range can be used as enclosed hoist for people and loads all around the world without any restrictions. It has been designed to correspond exactly to the international regulations (e.g. EN 12159).You may exchange the standard automatic control with the optional, even more user friendly level pre-selection control. For safety reasons the 2.5 m high enclosure is electrically and mechanically blocked. This means the door of the enclosure can only be opened when the hoist is in the base unit.
Product Specifications
Additional Information
The Multilift Standard range is in no way technically inferior to the Comfort series, but its use depends on the regulations in the respective countries it is used. The hoists are delivered with an electrically surveyed low enclosure. This means that you cannot make the platform leave the base unit or that the platforms stops when a door is opened.Assembly is not carried out from the roof.
Platform Dimension Platform Height
2.1 m
Platform Dimension Platform Length
3.2 m
Platform Dimension Platform Width
1.4 m
Power Supply Current
63 A
Power Supply Frequency
50 Hz | 60 Hz
Power Supply Power
30 kW
Power Supply Voltage
380 to 480 V
Specifications Cargo
Material | Persons
Specifications Lifting Height
200 m
Specifications Lifting Speed
54 m/min
Specifications Load Capacity
22 Persons
Specifications Mast System
GEDA VARIO-MAST
Specifications Material Load Capacity
2,000 kg
Specifications Place Of Origin
Germany
