Glass Melamine Sheet - NEMA G-9
Glass Melamine Sheet - NEMA G-9
SKU:SHA-3d996f
Premium glass melamine sheet with exceptional hardness and dimensional stability. Meets MIL-I-24768/1 Type GME standards.
Regular price
$79.99
Regular price
Sale price
$79.99
Unit price
per
Initiate Order
Glass Melamine Sheet - NEMA G-9
$79.99
Quantity: 1
Claim Your Seller Account
Glass Melamine Sheet - NEMA G-9
$79.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Glass Melamine Sheet, complying with MIL-I-24768/1 Type GME standards, is a premium thermoset composite laminate. Crafted with a continuous glass woven cloth base and melamine resin, this sheet offers superior hardness, dimensional stability, and arc resistance. Ideal for various mechanical and electrical applications due to its exceptional physical strength, resiliency, and excellent electrical properties. With specifications meeting rigorous ASTM standards, including high tensile and flexural strengths, this sheet is reliable for demanding institutional and government procurement needs.
Product Specifications
Specifications Coefficient Of Thermal Expansion Crosswise
1.0 x 10-5 in/in/ºF
Specifications Coefficient Of Thermal Expansion Lengthwise
0.83 x 10-5 in/in/ºF
Specifications Compressive Strength
70000 psi
Specifications Density Astm D792
1.95 g/cm³
Specifications Dielectric Strength Short Time 0125 Astm D149
550 V/mil
Specifications Flammability Rating Ul 94
V0
Specifications Flexural Modulus Crosswise Astm D790
13 x 105 psi
Specifications Flexural Modulus Lengthwise Astm D790
16 x 105 psi
Specifications Flexural Strength Crosswise Astm D790
58000 psi
Specifications Flexural Strength Lengthwise Astm D790
82000 psi
Specifications Hardness Rockwell Astm D785
M120
Specifications Izod Impact Strength Notched Crosswise Astm D256
9 ft·lb/in
Specifications Izod Impact Strength Notched Lengthwise Astm D256
16 ft·lb/in
Specifications Maximum Operating Temperature
300 ºF
Specifications Sheet Size
36 x 48 in
Specifications Tensile Strength Crosswise Astm D638
32000 psi
Specifications Tensile Strength Lengthwise Astm D638
41000 psi
Specifications Thickness
0.312 in
Specifications Tolerance
± 0.0175 in
Specifications Water Absorption 24 Hrs At 0125 Astm D570
0.28 %
Specifications Weight
3.10 lb/ft²
