The TX-1100DRAP Oxygen Deficiency Monitor is specifically designed for gloveboxes in semiconductor facilities, clean rooms, and laboratories. It detects oxygen levels as low as 5% within inert nitrogen environments. With a digital display and a 4-20 mA analog output range, this monitor offers accurate readings and dual-level alarm relay contacts for added safety. Its robust zirconium oxide sensor cell ensures ±1% accuracy, while the polycarbonate enclosure guarantees durability. Additionally, this monitor requires no calibration and boasts a sensor lifespan of over 10 years, making it a reliable long-term investment for maintaining controlled environments.
Product Specifications
Options Options
24 VDC Power Supply (P/N 45101)Horn and Strobe Combo (P/N 42002)Remote Display (P/N 99091)
Specifications Accuracy
± 1 % of Full Scale
Specifications Current
250 mA
Specifications Depth
3.25 in | 82.5 mm
Specifications Digital Display Analog Output Range
4 to 20 mA
Specifications Direct Current Dc Voltage
24 V
Specifications Display
Long life zirconium oxide sensor cell
Specifications Enclosure Material
Polycarbonate
Specifications Gases Detected
Oxygen (O2)
Specifications Height
4.5 in | 114.3 mm
Specifications Operating Temperature
-40 to +55 ºC
Specifications Oxygen Range
0 to 25 %
Specifications Required Calibration
NoneNo Zero or Span Pot Adjustment Required
Specifications Sampling Method
Diffusion
Specifications Sensor Life
10 plus years under Normal Conditions
Specifications Signal Outputs
4-20 mA Analog Output Dual Level Alarm Relay Contacts
Specifications Weight
1.6 lb | 0.8 kg
Specifications Width
5.125 in | 130. mm
Standard Features 0
Designed for mounting on Gloveboxes10 + Years No Calibration SensorTwo-Alarm Relays for 19.5% and 18.0%No Maintenance RequiredUltra Loud Built-in audible alarm 90 DB3 Year WarrantyNo Drift due to Thunderstorms or barometric pressure changesLocal display, 4-20mA outputUL, C UL and CE Approvals
