GO Regulator BP-6 Stainless Steel Back Pressure Regulator
GO Regulator BP-6 Stainless Steel Back Pressure Regulator
SKU:GOP-1aaa85
Versatile GO Regulator BP-6 Stainless Steel Back Pressure Regulator with 0-100 psig control range for reliable performance in diverse applications.
Regular price
$299.99
Regular price
Sale price
$299.99
Unit price
per
Initiate Order
GO Regulator BP-6 Stainless Steel Back Pressure Regulator
$299.99
Quantity: 1
Claim Your Seller Account
GO Regulator BP-6 Stainless Steel Back Pressure Regulator
$299.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The GO Regulator BP-6 High Flow Back Pressure Regulator is a versatile solution designed for reverse osmosis water purification systems, pilot facilities, and large instrumentation setups. Constructed with durable 316L stainless steel and a stainless steel diaphragm, this regulator offers reliable performance in various chemical environments. The standard polytetrafluoroethylene (PTFE) diaphragm facing material ensures precise control within the 0 to 100 psig range. With options for soft seat for tight shutoff, panel mounting, extra ports, and special welded connections, the BP-6 Series caters to diverse application needs. Ideal for gas or liquid service, the metal to metal seat construction ensures durability and efficiency.
Product Specifications
Features And Benefits Features And Benefits
Gas or liquid serviceSensing with Polytetrafluoroethylene (PTFE) lined stainless diaphragmMetal to metal seat
Note Note
The choices above represent an abbreviated list of the more commonly ordered options.
Options Options
Soft seat for bubble tight shutoffPanel mountingExtra portsSpecial welded connectionsPressure gauges
Specifications Actuator Material
316L Stainless Steel
Specifications Body Material
316L Stainless Steel, Stainless Steel Diaphragm
Specifications Cap Assembly
T-Handle, Stainless Steel
Specifications Cavity Finish
< 25 Ra
Specifications Control Range
0 to 100 psig
Specifications Diaphragm Backing Material
Metal Backing
Specifications Diaphragm Facing Material
Polytetrafluoroethylene (PTFE)
Specifications Diaphragm Type
Standard Diaphragm
Specifications Flow Coefficient Cv
0.3
Specifications Gauge Port Size
1/4 in
Specifications Gauge Port Types
Female National Pipe Tapered (FNPT)
Specifications Port Configuration
Standard
Specifications Process Port Size
1/2 in
Specifications Process Port Types
Female National Pipe Tapered (FNPT)
Specifications Weight
4.3 lb | 1.95 kg
Technical Data Inlet And Outlet Connections
1/2 in. Female National Pipe Tapered (FNPT)
Technical Data Operating Temperature
-40 to +500 ºF | -40 to +260 ºC
Applications Applications
Pilot plantsLarge instrumentation systemsReverse osmosis water purification systems
