GO Regulator BP-66 High Back Pressure Regulator
GO Regulator BP-66 High Back Pressure Regulator
SKU:GOP-828137
High-performance BP-66 High Back Pressure Regulator with 0-6000 psig control range and Polyimide actuator material for precise pressure management.
Regular price
$499.99
Regular price
Sale price
$499.99
Unit price
per
Initiate Order
GO Regulator BP-66 High Back Pressure Regulator
$499.99
Quantity: 1
Claim Your Seller Account
GO Regulator BP-66 High Back Pressure Regulator
$499.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The GO Regulator BP-66 High Back Pressure Regulator, featuring a control range of 0 to 6000 psig and Polyimide actuator material, is designed to excel in high-pressure systems with low to moderate flows. Its piston sensing mechanism ensures relief at high pressures, while the Polyimide/stainless seat assembly guarantees reliable shutoff. This regulator offers exceptional sensitivity, diverse control ranges, and is ideal for research and pilot plant facilities seeking precision and economy.
Product Specifications
Features And Benefits Features And Benefits
Spring-loaded piston sensorGas and liquid serviceFluorocarbon (FKM) seals (other elastomers optional)
Note Note
The choices above represent an abbreviated list of the more commonly ordered options.
Options Options
Panel mountingMonel® and titanium body constructionCv of 0.01 or 0.12AN 10050-4, SAE J514, MS 33649 or 3/8" FNPT connections
Specifications Actuator Material
Polyimide
Specifications Body Material
316L Stainless Steel
Specifications Cap Assembly
Standard, Aluminum
Specifications Cavity Finish
< 25 Ra
Specifications Control Range
0 to 6000 psig
Specifications Flow Coefficient Cv
0.04
Specifications Gauge Port Size
1/4 in
Specifications Gauge Port Types
Female National Pipe Tapered (FNPT)
Specifications Piston Material
Stainless Steel with Standard Fluorocarbon (FKM) Cavity O-Ring
Specifications Piston Type
Standard
Specifications Port Configuration
Standard
Specifications Process Port Size
1/4 in
Specifications Process Port Types
Female National Pipe Tapered (FNPT)
Specifications Weight
4.4 lb | 2.0 kg
Technical Data Inlet And Outlet Connections
1/4 in. Female National Pipe Tapered (FNPT) (Standard) Aerospace Standard (AS) 10050-4, Society of Automotive Engineers (SAE) J514, Military Standard (MS) 33649, or 3/8" Female National Pipe Tapered (FNPT) (Optional)
Technical Data Operating Temperature
-40 to +350 ºF | -40 to +177 ºC
Applications Applications
Pilot plantsResearch labs
