GO Regulator BP-66 High Back Pressure Regulator
GO Regulator BP-66 High Back Pressure Regulator
SKU:GOP-7f85ba
GO Regulator BP-66 High Back Pressure Regulator with PEEK™ Actuator Material. Ideal for high-pressure systems. Promotes precise pressure control.
Regular price
$289.99
Regular price
Sale price
$289.99
Unit price
per
Initiate Order
GO Regulator BP-66 High Back Pressure Regulator
$289.99
Quantity: 1
Claim Your Seller Account
GO Regulator BP-66 High Back Pressure Regulator
$289.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The GO Regulator BP-66 High Back Pressure Regulator is designed for systems with high pressure and low to moderate flows. Featuring a piston sensor for precise relief at high pressures and a Polyetheretherketone (PEEK™) actuator material, this regulator ensures reliable performance. With a sturdy stainless steel body, standard port configuration, and a control range of 0 to 4000 psig, it is suitable for research labs, pilot plants, and industrial applications. The regulator offers excellent shutoff with its Polyimide/stainless seat assembly and comes with options for customizations like panel mounting and different body constructions.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Features And Benefits Features And Benefits
Spring-loaded piston sensorGas and liquid serviceFluorocarbon (FKM) seals (other elastomers optional)
Note Note
The choices above represent an abbreviated list of the more commonly ordered options.
Options Options
Panel mountingMonel® and titanium body constructionCv of 0.01 or 0.12AN 10050-4, SAE J514, MS 33649 or 3/8" FNPT connections
Specifications Actuator Material
Polyetheretherketone (PEEKâ¢)
Specifications Body Material
316L Stainless Steel
Specifications Cap Assembly
Standard, Aluminum
Specifications Cavity Finish
< 25 Ra
Specifications Control Range
0 to 4000 psig
Specifications Flow Coefficient Cv
0.01
Specifications Gauge Port Size
1/4 in
Specifications Gauge Port Types
Female National Pipe Tapered (FNPT)
Specifications Piston Material
Stainless Steel with optional Polytetrafluoroethylene (PTFE) Cavity O-Ring
Specifications Piston Type
Standard
Specifications Port Configuration
Standard
Specifications Process Port Size
1/4 in
Specifications Process Port Types
Female National Pipe Tapered (FNPT)
Specifications Weight
4.4 lb | 2.0 kg
Technical Data Inlet And Outlet Connections
1/4 in. Female National Pipe Tapered (FNPT) (Standard) Aerospace Standard (AS) 10050-4, Society of Automotive Engineers (SAE) J514, Military Standard (MS) 33649, or 3/8" Female National Pipe Tapered (FNPT) (Optional)
Technical Data Operating Temperature
-40 to +350 ºF | -40 to +177 ºC
Applications Applications
Pilot plantsResearch labs
