GO Regulator BP-66 High Back Pressure Regulator with 0-4000 psig Control Range
GO Regulator BP-66 High Back Pressure Regulator with 0-4000 psig Control Range
SKU:GOP-9c916c
High-performance back pressure regulator with 0-4000 psig control range, ideal for research labs and pilot plants.
Regular price
$359.99
Regular price
Sale price
$359.99
Unit price
per
Initiate Order
GO Regulator BP-66 High Back Pressure Regulator with 0-4000 psig Control Range
$359.99
Quantity: 1
Claim Your Seller Account
GO Regulator BP-66 High Back Pressure Regulator with 0-4000 psig Control Range
$359.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The GO Regulator BP-66 High Back Pressure Regulator is designed for applications requiring higher pressure and moderate flows. Featuring a piston sensing system for relief at high pressures, this regulator offers excellent shutoff with its Polyimide/stainless seat assembly. The Polyetheretherketone (PEEK™) actuator material ensures durability and reliability. With a variety of control ranges and a lightweight aluminum construction, this regulator is ideal for research labs and pilot plants.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Features And Benefits Features And Benefits
Spring-loaded piston sensorGas and liquid serviceFluorocarbon (FKM) seals (other elastomers optional)
Note Note
The choices above represent an abbreviated list of the more commonly ordered options.
Options Options
Panel mountingMonel® and titanium body constructionCv of 0.01 or 0.12AN 10050-4, SAE J514, MS 33649 or 3/8" FNPT connections
Specifications Actuator Material
Polyetheretherketone (PEEKâ¢)
Specifications Body Material
316L Stainless Steel
Specifications Cap Assembly
Standard, Aluminum
Specifications Cavity Finish
< 25 Ra
Specifications Control Range
0 to 4000 psig
Specifications Flow Coefficient Cv
0.04
Specifications Gauge Port Size
1/4 in
Specifications Gauge Port Types
Female National Pipe Tapered (FNPT)
Specifications Piston Material
Stainless Steel with optional Polytetrafluoroethylene (PTFE) Cavity O-Ring
Specifications Piston Type
Standard
Specifications Port Configuration
Standard
Specifications Process Port Size
1/4 in
Specifications Process Port Types
Female National Pipe Tapered (FNPT)
Specifications Weight
4.4 lb | 2.0 kg
Technical Data Inlet And Outlet Connections
1/4 in. Female National Pipe Tapered (FNPT) (Standard) Aerospace Standard (AS) 10050-4, Society of Automotive Engineers (SAE) J514, Military Standard (MS) 33649, or 3/8" Female National Pipe Tapered (FNPT) (Optional)
Technical Data Operating Temperature
-40 to +350 ºF | -40 to +177 ºC
Applications Applications
Pilot plantsResearch labs
