GO Regulator HPR-2 Steam Heated Regulator
GO Regulator HPR-2 Steam Heated Regulator
SKU:GOR-601859
Enhance sample conditioning with GO Regulator HPR-2 Steam Heated Regulator for reliable vaporization and precision control in critical industrial applications.
Regular price
$599.99
Regular price
Sale price
$599.99
Unit price
per
Initiate Order
GO Regulator HPR-2 Steam Heated Regulator
$599.99
Quantity: 1
Claim Your Seller Account
GO Regulator HPR-2 Steam Heated Regulator
$599.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The GO Regulator HPR-2 Series Steam Heated Regulator offers precise control and heating capabilities for analytical process sample conditioning systems in industries such as petrochemical refineries, chemical production facilities, and LNG points. With a modular design featuring a spiral-wrapped heat exchange element providing up to 100 square inches of heat transfer area, this regulator ensures optimal performance and reliable vaporization of liquids. Its bubble-tight shutoff, tamper-proof cap assembly, and electro-polished body with superior finish make it ideal for demanding industrial environments. Meet institutional procurement standards with the optional Hastelloy C and Monel materials, complying with industry certifications for quality assurance.
Product Specifications
Specifications Applications
Analytical process sample conditioning systems: Petro chemical refineries Chemical production facilitiesPilot plants (chemical & petro chemical) LNG loading and off-loading pointsNatural gas pipeline sampling
Specifications Body Material
316L Stainless Steel
Specifications Cap Assembly
Tamper-proof, standard, stainless steal
Specifications Features Benefits
Optional Hastelloy® C and Monel® Electropolished body with better than 25 Ra finishin diaphragm cavity for an optimal sealing surfaceBubble-tight shutoffModular pressure control and heat exchangerassemblies allow for easy maintenance Unique spiral-wrapped heat exchange elementprovides up to 100 square inches of heat transfer area.
Specifications Flow Coefficient Cv
0.06
Specifications Heater Block Porting
Standard
Specifications Heater Block Type
Steam
Specifications Heater Wattage
Steam
Specifications Inlet
1/8" FNPT
Specifications Max Operating Pressure
3600 psig
Specifications Max Temperature
193 ºC | 380 ºF
Specifications Outlet
1/4" Female NPT
Specifications Outlet Range
0 to 10 psig
Specifications Port Configuration
C
Specifications Seat Material
Polyimide
Specifications Surface Finish Of Diaphragm Cavity
< 25 Ra, Standard
Specifications Temperaturepressure
380° F@3600 psig
