The GO Regulator MR-1 0.025 Flow Coefficient Ultra Miniature Single Stage Pressure Regulator is built for precision and versatility. With an internal volume of less than 2.7cm³, 316L Stainless Steel construction, and Tefzel® components, it ensures reliable performance in gas or liquid services. The regulator offers a Cv flow coefficient of 0.025, bubble-tight shutoff, and a range of outlet pressure options to suit various applications. Ideal for compact and sophisticated instrumentation requiring precise pressure control.
Product Specifications
Features And Specifications Features And Specifications
Gas or liquid service316L stainless steel constructionInternal volume is less than 2.7cc20 micron inlet filterBubble-tight shutoffOutlet pressure ranges are 0 - 10, 0 - 25, 0 - 50, 0 - 100, 0 - 250 and 0 - 500 psigCv flow coefficient 0.025 or 0.06Option: surface mount (for manifolds)Optional INCONEL® diaphragm
Options Options
Certificate of Conformity
Specifications Body Material
316L Stainless Steel
Specifications Cap Assembly
Tamper-Proof
Specifications Diaphragm Backing Material
Stainless Steel
Specifications Diaphragm Facing Material
Tefzel® Ring
Specifications Diaphragm O Ring Material
Polytetrafluoroethylene (PTFE)
Specifications Diaphragm Type
Standard, Nylon Diameter Slip Ring (170 °F Maximum Temperature)
Specifications Flow Coefficient Cv
0.025
Specifications Inlet Filter
20 µm
Specifications Internal Volume
< 2.7 cm³
Specifications Note
Contact the factory for any additional requirements.
Specifications Outlet Range
0 to 250 psig (Requires T-handle or Tamper-Proof)
Specifications Port Configuration
1
Specifications Port Types
Surface Mount
Specifications Seat Material
Tefzel®
Specifications Surface Finish Of Diaphragm Cavity
< 25 Ra
