Godwin CD400M Contractor Dewatering Centrifugal Pump
Godwin CD400M Contractor Dewatering Centrifugal Pump
SKU:GOD-3f26e3
High-capacity Dri-Prime® Contractor Pump with 9770 USGPM flow rate, automatic priming, and durable construction for reliable dewatering operations.
Regular price
$15,999.99
Regular price
Sale price
$15,999.99
Unit price
per
Initiate Order
Godwin CD400M Contractor Dewatering Centrifugal Pump
$15,999.99
Quantity: 1
Claim Your Seller Account
Godwin CD400M Contractor Dewatering Centrifugal Pump
$15,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Godwin CD400M Contractor Dewatering Centrifugal Pump from the renowned Dri-Prime® series is a high-performance pump designed for demanding applications. With a maximum capacity of 9770 USGPM and the ability to handle solids up to 4.9 inches in diameter, this pump ensures efficient dewatering operations. Featuring automatic priming to 28 feet of suction lift, it offers versatile control options through the integral mounted control panel or optional wireless access. Constructed with high-quality materials such as cast iron, carbon steel, and stainless steel components, this pump guarantees durability and reliability even in challenging environments. Ideal for contractors and government agencies requiring top-tier performance and compliance with industry standards.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Materials Impeller
Cast Steel BS3100 A5 Hardness to 200 HB Brinell
Materials Mechanical Seal
Double Mechanical Seal; Silicon Carbide Face; Viton Elastomers; Stainless Steel Body
Materials Non Return Valve Body
Cast Iron BS EN 1561 - 1997
Materials Pump Casing And Suction Cover
Cast Iron BS EN 1561:1997
Materials Pump Shaft
Carbon Steel BS 970:1991 817M40T
Materials Wearplates
Cast Iron BS EN 1561 - 1997
Note 0
All information is approximate and for general guidance only.© 2014 Xylem, Inc. All rights reserved. Godwin is a trademark of Xylem Dewatering Solutions, Inc., a wholly-owned subsidiary of Xylem Inc. Specifications and illustrations are subject to revision without notice. Xylem makes no representation regarding the completeness or accuracy of this information and is not liable for any direct or indirect damages arising from or relating to this information or its use.
Specifications Control Options
Automatic | Manual
Specifications Delivery Connection
18 in. 150# ANSI B16.5
Specifications Maximum Capacity
9770 USGPM
Specifications Maximum Casing Pressure
96 psi
Specifications Maximum Impeller Diameter
19.7 in
Specifications Maximum Operating Speed
1200 rpm
Specifications Maximum Operating Temperature
176 ºF
Specifications Maximum Pressure
64 psi
Specifications Maximum Solids Handling
4.9 in
Specifications Maximum Suction Pressure
44 psi
Specifications Series
CD
Specifications Suction Connection
18 in. 125# ANSI B16.1
Specifications Suction Lift
28 ft
