Godwin HL Series Dri-Prime High Lift Centrifugal Pump
Godwin HL Series Dri-Prime High Lift Centrifugal Pump
SKU:GOD-007550
Powerful Godwin HL Series Dri-Prime Pump with 500 GPM capacity, 265 psi max pressure, and automatic/manual operation.
Regular price
$5,999.99
Regular price
Sale price
$5,999.99
Unit price
per
Initiate Order
Godwin HL Series Dri-Prime High Lift Centrifugal Pump
$5,999.99
Quantity: 1
Claim Your Seller Account
Godwin HL Series Dri-Prime High Lift Centrifugal Pump
$5,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Godwin HL Series 500 GPM Dri-Prime High Lift Centrifugal Pump is a robust solution for both commercial and government applications, delivering a maximum capacity of 500 USGPM. With a maximum working pressure of 265 psi, this pump is designed to handle tough pumping challenges with ease. Equipped with advanced features like automatic priming to 28 feet of suction lift, a durable cast steel pump casing, and high chrome wearplates, this pump ensures reliable performance in demanding environments. The integrated control panel offers convenient automatic or manual operation, making it versatile for various applications.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Materials Impeller
Cast Steel BS3100 A5 Hardness to 200 HB Brinell
Materials Mechanical Seal
Silicon Carbide Face; Viton Elastomers; Stainless Steel Body
Materials Non Return Valve Body
Cast Steel
Materials Pump Casing And Suction Cover
Cast Steel BS3100 A5
Materials Pump Shaft
Carbon Steel BS 970:1991 817M40T
Materials Wearplates
High Chrome Cast Iron Hardened to 625 HB Brinell
Note 0
All information is approximate and for general guidance only.© 2014 Xylem, Inc. All rights reserved. Godwin is a trademark of Xylem Dewatering Solutions, Inc., a wholly-owned subsidiary of Xylem Inc. Specifications and illustrations are subject to revision without notice. Xylem makes no representation regarding the completeness or accuracy of this information and is not liable for any direct or indirect damages arising from or relating to this information or its use.
Specifications Control Options
Automatic | Manual
Specifications Delivery Connection
3 in. 300# ANSI B16.5
Specifications Maximum Capacity
500 USGPM
Specifications Maximum Casing Pressure
398 psi
Specifications Maximum Impeller Diameter
18.3 in
Specifications Maximum Operating Speed
2200 rpm
Specifications Maximum Operating Temperature
176 ºF
Specifications Maximum Solids Handling
0.8 in
Specifications Maximum Suction Pressure
87 psi
Specifications Maximum Working Pressure
265 psi
Specifications Series
HL
Specifications Suction Connection
4 in. 150# ANSI B16.5
Specifications Suction Lift
28 ft
