Gold-Plated SMA Female Jack Receptacles with Solder End
Gold-Plated SMA Female Jack Receptacles with Solder End
SKU:SMA-d7beff
High-performance SMA female jack receptacles with gold plating, ideal for DC-18GHz applications. Bulk packaging of 100 pcs.
Regular price
$149.99
Regular price
Sale price
$149.99
Unit price
per
Initiate Order
Gold-Plated SMA Female Jack Receptacles with Solder End
$149.99
Quantity: 1
Claim Your Seller Account
Gold-Plated SMA Female Jack Receptacles with Solder End
$149.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Experience superior signal transmission and reliability with our Gold-Plated SMA Female Jack Receptacles. These connectors feature a high-quality gold-plated body, panel mount configuration, and are designed for a cable dielectric dia. of .066/.117 inches. With a 50 ohms impedance and a frequency range of DC - 18 GHz, these receptacles are ideal for demanding applications. Packaged in bulk (100 pcs), they are perfect for industrial and institutional projects requiring top-tier connectivity solutions.
Product Specifications
Specifications Cable Dielectic Dia Inches
.066/.117
Specifications Configuration
panel mount receptacle
Specifications Connection
female
Specifications Connector Series
SMA
Specifications Frequency Range Ghz
DC - 18
Specifications Impedence Ohms
50
Specifications Packaging
bulk 100 pcs.
Specifications Plating Body
gold
