Goodfellow Corp. Silicon Carbide Monofilament
Goodfellow Corp. Silicon Carbide Monofilament
SKU:SIL-086dd2
High-performance Silicon Carbide monofilament with 0.1mm diameter, coated for durability and adhesion. Ideal for extreme temperature applications.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Goodfellow Corp. Silicon Carbide Monofilament
$39.99
Quantity: 1
Claim Your Seller Account
Goodfellow Corp. Silicon Carbide Monofilament
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Goodfellow Corp. Silicon Carbide Monofilament is a high-performance non-metallic strand coated with pyrolitic Carbon and Titanium Diboride, offering exceptional durability and adhesion to Titanium alloys. With a diameter of 0.1 mm and length ranging from 1 to 10 meters, this monofilament boasts superior mechanical properties including a Vickers hardness of 2500 Kgf mm-2 and a tensile modulus of 400.00 GPa. Its thermal properties, resistant to extreme temperatures with a melting point of 2650.00 to 2950.00 ºC, make it ideal for demanding applications. Crafted through a state-of-the-art chemical vapor deposition (CVD) process, this monofilament meets the stringent standards of both consumer and institutional buyers.
Product Specifications
Material Material
Silicon CarbideSilicon Carbide was first prepared in the early 1800's. It was in commercial production by 1892, as a powder for grinding and cutting, having a Mohs hardness of 9-10 (almost as hard as Diamond). Nicalon continuous multi-filament tow consists of fine filaments of ultra-fine Ã-SiC crystals, giving strong particle bonding. This fiber has high strength and a high modulus in a high temperature atmosphere. It is oxidation resistant, with a high wettability and is consequently used in composites with metals, plastics and ceramics. A thicker monofilament, also used for composites, is also available from Goodfellow in 3 versions which differ only in their outer coating (used to improve adhesion to, and resist degradation by, the matrix of a composite). This monofilament is made by a chemical vapor deposition (CVD) process around a fine tungsten wire.
Mechanical Properties Form Tensile Modulus Form
400.00 GPa
Mechanical Properties Form Tensile Strength Form
3.50 to 3.75 MPa
Mechanical Properties Hardness Vickers
2500 Kgf mm-2
Physical Properties Form Density Form
3.400 g·cm-3
Specifications Diameter
0.1 mm
Specifications Form
Monofilament
Specifications Length
1 to 10 m
Specifications Tungsten Diameter
0.01 mm
Thermal Properties Melting Point
2650.00 to 2950.00 ºC
Tolerances Diameter Tolerance
20 %
Tolerances Tolerance For Length Round
-1 % | +5 %
Type Type
CeramicCeramics are non-metallic, non-organic materials. They exhibit excellent resistance to high temperatures. Although they have comparatively low densities, they are extremely hard but tend to be brittle. They show good resistance to both abrasives and chemicals.
