Goulds Submersible Pump with Underground Discharge
Goulds Submersible Pump with Underground Discharge
SKU:PUM-5004ce
High-performance Goulds Submersible Pump with Underground Discharge. Hermetically sealed and wet winding motors ensure reliability across various applications.
Regular price
$2,399.99
Regular price
Sale price
$2,399.99
Unit price
per
Initiate Order
Goulds Submersible Pump with Underground Discharge
$2,399.99
Quantity: 1
Claim Your Seller Account
Goulds Submersible Pump with Underground Discharge
$2,399.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Goulds Submersible Pump with Underground Discharge is a cutting-edge solution that seamlessly integrates turbine pump hydraulic engineering with advanced electric submersible motors. It features a hermetically sealed type motor that ensures optimal performance and durability in diverse applications such as municipal, wastewater plants, commercial/industrial settings, agricultural irrigation, mining, cooling towers, water parks, snowmaking, and flood control. The wet winding type motor provides efficient heat dissipation and reliable operation, making it ideal for demanding environments. This pump comes equipped with a range of essential submersible accessories for complete functionality and ease of installation.
Product Specifications
Hermetically Sealed Type 0
A Hermetically Sealed Type motor utilizes windings of standard construction and insulation thickness. The windings are encased and Hermetically Sealed within the external shell casing on the outside and an internal tube or liner inside the bore. The Hermetically Sealed enclosure eliminates the possibility of water leakage into the winding the liquid medium circulates between the rotor and stator liner providing lubrication and cooling to the bearings.
Specifications Applications
Municipal | Wastewater Plants | Commercial/Industrial | Agricultural Irrigation | Dewatering | Mining | Cooling Tower | Water Parks | Snowmaking | Flood Control
Specifications Manufacturer
Goulds Pumps
Specifications Type
U
Submersible Accessories 0
Valves Check Valves Flow Control Gate Valves Ball Valves Electrical Panels Furnas Panels V.F.D. Drivers Pitless Adapters Wire 12 to 0000 Heat Shrinks Splice Kits Tanks Well Heads Submersible Discharge Head Torque Arrestors Gauges Motor Shrouds
Wet Winding Type 0
A Wet Winding Type motor is one in which the motor windings are in direct contact with a liquid medium. The medium is clean, clear water. A pressure balancing system prevents exchange of the motor liquid medium and well water due to thermal expansion and contraction when the motor is operating. The liquid medium fills the inside of the motor and surrounds both the stator windings and the rotor. A completely water proof insulation is used on the magnet wire used for the stator windings. The liquid medium inside the motor air gap and coils acts as a heat transfer device by circulating through the windings and transferring heat to the external casing. Dissipation of this heat occurs as the well water flows at a required velocity over the external case. As is the case in all submersible type motors, the internal liquid medium is also used for bearing lubrication.
