Gray 3-Pin Wire Mount Plug Connector
Gray 3-Pin Wire Mount Plug Connector
SKU:PRO-aa9f2f
Reliable 3-pin wire mount plug connector for secure electrical connections. Maximum rated current 3.0A, compatible with 22-20 AWG wire sizes.
Regular price
$2.10
Regular price
Sale price
$2.10
Unit price
per
Initiate Order
Gray 3-Pin Wire Mount Plug Connector
$2.10
Quantity: 1
Claim Your Seller Account
Gray 3-Pin Wire Mount Plug Connector
$2.10
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Gray 3-Pin Wire Mount Plug Connector is a premium solution for secure and efficient electrical connections. Designed to handle a maximum rated current of 3.0A and compatible with wire sizes ranging from 22-20 AWG, this connector ensures reliable performance. With a robust build that includes Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) body material and C5210 terminal material with Gold plating, it meets high industry standards for durability and conductivity. The connector's compliance with UL94V-0 and various technical specifications makes it ideal for a wide range of applications requiring precision and quality.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Gray
Specifications Connector Type
Wire Mount Plug
Specifications Cover Color
Gray
Specifications Cover Diameter
1.6 to 2.0 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.32 to 0.5 mm²
Specifications Number Of Pins
3
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.32 to 0.5 mm²
Specifications Wire Size
22-20 AWG
