Gray 3-Pin Wire Mount Socket Connector
Gray 3-Pin Wire Mount Socket Connector
SKU:PRO-8b7ee2
Reliable Gray 3-Pin Wire Mount Socket Connector for diverse connectivity needs. Meets industry standards for optimal performance.
Regular price
$2.10
Regular price
Sale price
$2.10
Unit price
per
Initiate Order
Gray 3-Pin Wire Mount Socket Connector
$2.10
Quantity: 1
Claim Your Seller Account
Gray 3-Pin Wire Mount Socket Connector
$2.10
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Gray 3-Pin Wire Mount Socket Connector is a high-quality solution for your connectivity needs. With a maximum AC/DC voltage of ~250V, this connector is designed with C5210 gold terminal material and a sturdy Polycarbonate/ABS body, ensuring reliability and durability. It meets sensor connector standards and supports wire sizes of 22-20 AWG. With a maximum rated current of 3.0A and secure terminal retention of 1.4 kgf, this connector offers optimal performance. Whether for consumer or institutional use, this connector is a versatile choice.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Gray
Specifications Connector Type
Wire Mount Socket
Specifications Cover Color
Gray
Specifications Cover Diameter
1.6 to 2.0 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.32 to 0.5 mm²
Specifications Number Of Pins
3
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.32 to 0.5 mm²
Specifications Wire Size
22-20 AWG
