Gray 4-Pin Wire Mount Socket Connector

Gray 4-Pin Wire Mount Socket Connector

PRO-274876

Reliable Gray 4-Pin Wire Mount Socket Connector for secure and efficient connectivity.

$2.10
$2.10
Sale

Initiate Order

Gray 4-Pin Wire Mount Socket Connector

Gray 4-Pin Wire Mount Socket Connector

$2.10

Quantity: 1

Claim Your Seller Account

Gray 4-Pin Wire Mount Socket Connector

Gray 4-Pin Wire Mount Socket Connector

$2.10

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Gray 4-Pin Wire Mount Socket Connector is a precision-engineered connectivity solution designed for optimal performance. With a Terminal Material of C5210 (Gold 0.2 μm) and a Body Material of Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0), this sensor connector ensures high durability and reliability. It features a maximum rated current of 3.0 A and supports AWG20 to AWG22 wires, making it ideal for a wide range of applications. The connector meets industry standards for quality and safety, providing peace of mind for both consumer and institutional buyers.

Product Specifications

Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Gray
Specifications Connector Type
Wire Mount Socket
Specifications Cover Color
Gray
Specifications Cover Diameter
1.6 to 2.0 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.32 to 0.5 mm²
Specifications Number Of Pins
4
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.32 to 0.5 mm²
Specifications Wire Size
22-20 AWG
