Gray PVC Type II Sheet, 12x12x4 in
Gray PVC Type II Sheet, 12x12x4 in
SKU:SHA-edae6c
High-impact Gray PVC Type II Sheet with superior chemical resistance and compliance with ASTM D1784 & UL94 V0 standards. Ideal for thermal forming & durability.
Regular price
$45.99
Regular price
Sale price
$45.99
Unit price
per
Initiate Order
Gray PVC Type II Sheet, 12x12x4 in
$45.99
Quantity: 1
Claim Your Seller Account
Gray PVC Type II Sheet, 12x12x4 in
$45.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Gray PVC Type II Sheet is a high-impact polyvinyl chloride offering exceptional chemical resistance, dielectric properties, and mechanical strength. Compliant with ASTM D1784, CLASS 16444-D and UL94 V0 standards, it is ideal for demanding applications requiring thermal forming and resistance to physical abuse. With a Vicat Softening Point of 181°F, and a Heat Deflection Temperature of 179°F, this sheet provides durability and stability. Available in various sizes to suit your project needs.
Product Specifications
Specifications Density Astm D792
1.35 gm/cc
Specifications Dielectric Strength Astm D149
645 V/mil
Specifications Flame Spread E84
15
Specifications Flammability Rating Ul 94
V0
Specifications Flexural Modulus
400000 psi
Specifications Flexural Strength
10000 psi
Specifications Hardness Durometer Shore D
85
Specifications Hardness Rockwell Astm D785
R106
Specifications Heat Deflection Temperature 264 Psi
179 ºF
Specifications Izod Impact Strength Astm D256
18 ft·lb/in
Specifications Optional Sheet Size
12 x 24 | 12 x 36 | 24 x 120 | 24 x 24 | 24 x 96 | 36 x 48 | 48 x 48 | 48 x 72 | 60 x 120
Specifications Sheet Size
12 x 12 in
Specifications Tensile Modulus Astm D638
396000 psi
Specifications Tensile Strength Astm D638
7400 psi
Specifications Thickness
4.000 in
Specifications Vicat Softening Point Astm D1525
181 ºF
Specifications Water Absorption 24 Hrs 73f Astm D570
0.16 %
Specifications Weight
30.00 lb/ft²
