Green 3-Pin Wire Mount Socket Connector
Green 3-Pin Wire Mount Socket Connector
SKU:PRO-d961e7
High-quality Green 3-Pin Wire Mount Socket Connector for industrial applications. Terminal Material: C5210, Body Material: Polycarbonate/Acrylonitrile Butadiene Styrene (ABS), Max Voltage: ~250V, Rated Current: 3.0A.
Regular price
$2.10
Regular price
Sale price
$2.10
Unit price
per
Initiate Order
Green 3-Pin Wire Mount Socket Connector
$2.10
Quantity: 1
Claim Your Seller Account
Green 3-Pin Wire Mount Socket Connector
$2.10
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Green 3-Pin Wire Mount Socket Connector is a high-quality sensor connector designed for industrial applications. It features a Terminal Material of C5210 with Gold plating, ensuring reliable conductivity. The Body Material is Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) with a UL94V-0 rating for excellent safety. This connector meets Maximum Alternating Current/ Direct Current Voltage of ~250 V and is suitable for wires sized 22-20 AWG. With a rated current of 3.0 A and compliant with various standards, this connector is a dependable choice for both consumer and institutional buyers.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Green
Specifications Connector Type
Wire Mount Socket
Specifications Cover Color
Green
Specifications Cover Diameter
1.0 to 1.2 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.32 to 0.5 mm²
Specifications Number Of Pins
3
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.32 to 0.5 mm²
Specifications Wire Size
22-20 AWG
