Griff P-50195 Glassine Silicone Release Liner
Griff P-50195 Glassine Silicone Release Liner
SKU:FIL-5d6014
Griff's premium Glassine Silicone Release Liner ensures superior release properties with consistent performance for various applications.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
Griff P-50195 Glassine Silicone Release Liner
$29.99
Quantity: 1
Claim Your Seller Account
Griff P-50195 Glassine Silicone Release Liner
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Griff P-50195 Glassine Silicone Release Liner is a premium-grade release paper coated with solvent-less polymerized silicone on both sides, ensuring exceptional release properties for a wide range of applications. With a sturdy 55 lb basis weight and precise 3.0 mil caliper, this liner offers consistent performance. Designed for efficiency and reliability, this Havana-colored release liner delivers a release value of 1 to 15 g/in on both sides, meeting stringent industrial standards.
Product Specifications
Note
The information presented in this data sheet is believed to be accurate and is not intended to constitute a specification. The values given reflect average measurements, which can vary slightly. Users are encouraged to determine the suitability of this product for their own particular application(s).
Specifications Base Material
Glassine
Specifications Color
Havana
Specifications Release Treatment
Silicone Two Side
Specifications Type
Silicone Release
Terms And Conditions
Seller's only obligation shall be to replace such quantity of the product proven to be defective. Seller shall not be liable for any injury, loss or damage, direct or inconsequential, arising out of the use, or inability to use the product for his/her use, and the user assumes all risk and liability whatsoever in connection therewith. The foregoing may not be changed, except by an agreement signed by an officer or seller. We hereby certify that goods covered by this quotation have been produced in compliance with the Fair Labor Standards Act of 1983, as amended. Any credit memos to purchaser shall expire if not used within one year from date of credit memo.
Testing Parameters
Release test is measured in average grams per inch; 15 minute dwell time, 180° pull at 200 in/min. using Tesa 7475 Tape.
Test Results Control Limit For Basis Weight
52 to 58 lb
Test Results Control Limit For Caliper
2.7 to 3.3 mil
Test Results Control Limit For Release Value Side A
1 to 15 g/in
Test Results Control Limit For Release Value Side B
1 to 15 g/in
Test Results Control Limit For Yield
10 %
Test Results Basis Weight
55 lb
Test Results Caliper
3.0 mil
Test Results Release Value Side A
1 to 15 g/in
Test Results Release Value Side B
1 to 15 g/in
Test Results Yield
7,855 lb/in²
