Griplock® Art Suspension System - Professional Series
Griplock® Art Suspension System - Professional Series
SKU:THE-1cecc7
Hang art securely with Griplock® Art Suspension System - Professional Series. Adjust art with ease and support up to 50 lbs. Perfect for institutional use.
Regular price
$99.99
Regular price
Sale price
$99.99
Unit price
per
Initiate Order
Griplock® Art Suspension System - Professional Series
$99.99
Quantity: 1
Claim Your Seller Account
Griplock® Art Suspension System - Professional Series
$99.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Griplock® Art Suspension System - Professional Series revolutionizes art hanging, offering a safe and secure solution without nails or hooks. With functional elegance, this system supports up to 50 lbs with precision-built components and versatile cable options. Ideal for institutional settings, this system ensures quick and easy art repositioning. It meets Federal/DoD procurement standards, FAR compliance factors, and NIST standards, making it a top choice for government and institutional buyers.
Product Specifications
Additional Information 0
Griplock® Systems carries a broad selection of Cable Suspension components besides those shown or described here. Please contact us for further information on our comprehensive product line.Whether you’re hanging a show in SoHo, creating a window display on Fifth Avenue or suspending 3-dimensional artwork at the Getty, you can count on Griplock®.Gliders feature a precision-built internal mechanism that locks securely to the Cable yet can be released at the touch of a button. There are Gliders, Cable Couplers and Cables for every conceivable application.Griplock® Clamps are used for wall displays in conjunction with Art Track, or may be attached to Cables tensioned between stationary Cable Couplers. Display material can be either clamped or pinned using the M4 set-screws and hex key provided. Guide Clamps align the display to the Cable by locking to the display but sliding freely along the Cable.Cable Couplers create stationary attachment points on ceilings, floors and walls from which Cables can be suspended or tensioned. Tensioning from wall to wall or floor to ceiling requires a combination of adjustable and non-adjustable Couplers.Cable Couplers have separate base-plates that can be screwed or bolted to structural surfaces. Most base-plates have 1/4-20 internal threads that can be screwed onto 1/4-20 anchors or studs.
Art Track 0
The extruded aluminum Art Track is 80" long and can be screwed or bolted to any solid structure at any point along its length. When securely mounted, the Track will safely hold up to 50 lbs. every 16". The white PVC Track Cover slides or snaps into place and is available precut to 82". To cover a row of end to- end Track sections, continuous lengths up to 250' are available. The Track Cover is flexible and paintable. Cables may be added or removed via an escape hole on the underside of each Track section.
Features 0
FunctionalVersatileElegantThe Greater the Weight the Stronger it Grips
Griplock Cable 0
The single shank ball terminal allows the Cable to slide easily to any point on the Art Track. Griplock® 3/64" Stainless Steel Cable supports a maximum of 50 lbs. Other Cable sizes and terminals are available.
Note 0
Cable Gliders and Couplers in this brochure work with both 3/64" and 1/16" Cable unless noted. Nuts bolts and screws shown or mentioned are included with the product. Most illustrations are to scale.
Specifications Components
12-BS (Adjustable two-piece Coupler for <3/64" Cable.) | 15-BS for < 1/16" Cable | 15-FORK 8 x 16 Holds material < 5/16" thick | 15-SC-400-L / 15-SC-400-R Holds material < 13/32" thick | 15Z-1420-ELP (Adjustable two-piece Coupler.) | 15Z-TC-400 Holds material < 13/32" thick | 18-B4 for < 5/64" Cable | 18-HA Large Hook for < 5/64" Cable | 18-RI for < 5/64" Cable | 25-B5 for < 3/32" Cable | 25Z-M6-SL3.0 for < 3/32” Cable | 3/64" Stainless Steel Cable | 30-FORK 10 x 20 for < 1/8" Cable. Holds material < 3/8" thick | 30-RI-S for < 1/8" Cable | 50-FORK 14 x 28 for < 3/16" Cable. Holds material < 1/2" thick | 50-RI-S for < 3/16" Cable | Cable Collar CC-Q3.2 | Cable Couplers (Tensioning System) | CC-1420-ELP (Non-adjustable two-piece Coupler. Base-plate shown separated from Coupler.) | CC-1420-SL3.0 (Non-adjustable two-piece slotted Coupler for angled applications.) | CC-SC-400 Holds material < 13/32" thick | CC-SL4.5 for < 1/8" Cable | Deck Screw | Double Hanger 15-M5-2Q (Two M5 lock nuts incl. Locks displays together.) | Drill Starter Groove | End Cap | Fork and Locking Pin 15-FORK 6 x 24 (Holds material < 1/4" thick.) | Gated Hook 15-GHA (Locks securely to picture wire, strap hangers etc.) | Griplock® Clamps (For Signage and Display) | Guide Clamp CC-SC-250 (M4 set-screws & hex key incl. Holds material < 1/4" thick.) | Hanger 15-M5-Q (M5 lock nut incl. Bolts to displays.) | Picture Wire Glider/15Z-M6R-SL2.6 (Thumb-screw locks to picture wire.) | Quick Release Button | Quicklink (Locks Ring to displays.) | Ring 15-RI | RT-12-M8 (Adjustable two-piece Coupler for < 3/64" Cable.) | RT-15-M10 (Adjustable two-piece Coupler.) | RT-25-M13 for < 3/32" Cable | RT-CC-M10 (Non-adjustable two-piece Coupler.) | RT-CC-M13 for < 1/8" Cable | RT-CC-M8 (Non-adjustable two-piece Coupler.) | Side Clamp 15-SC-250-L / 15-SC-250-R (M4 set-screws & hex key incl. Holds material < 1/4" thick) | Single Shank Ball Cable Terminal | Small Hook 15-HA | The Griplock® Glider | Top Clamp 15Z-TC-250 (M4 set-screws & hex key incl. Holds material < 1/4" thick.) | Track Cover
Specifications Thread Size
1/4-20 Internal
Specifications Track Holding Capacity
50 lb
Specifications Track Length
80 in
