Griplok Brass Bulkhead Reducing Union - 3/8" TF x 1/4" TF
Griplok Brass Bulkhead Reducing Union - 3/8" TF x 1/4" TF
SKU:SSP-b6345a
Premium Griplok Brass Bulkhead Reducing Union for reliable 3/8" to 1/4" tube connections.
Regular price
$32.99
Regular price
Sale price
$32.99
Unit price
per
Initiate Order
Griplok Brass Bulkhead Reducing Union - 3/8" TF x 1/4" TF
$32.99
Quantity: 1
Claim Your Seller Account
Griplok Brass Bulkhead Reducing Union - 3/8" TF x 1/4" TF
$32.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Griplok Brass Bulkhead Reducing Union is a high-quality instrumentation tube fitting designed for secure and leak-free connections. This union features a durable brass body, with one end fitting for 3/8" tubes and the other for 1/4" tubes. Its straight shape and bulkhead specialty ensure reliable performance in various applications. With precise dimensions and a maximum panel thickness of 0.44 inches, this union is easy to install and provides excellent sealing. Ideal for industrial settings, it meets stringent industry standards for quality and performance.
Product Specifications
Dimensions A
2.44 in
Dimensions Ax
1.49 in
Dimensions B
1.81 in
Dimensions Bx
1.16 in
Dimensions Cx
0.70 in
Dimensions D
0.71 in
Dimensions Dx
0.60 in
Dimensions E
0.19 in
Dimensions G
11/16 in
Dimensions Gx
9/16 in
Dimensions H
3/4 in
Dimensions Hx
3/4 in
Dimensions Maximum Panel Thickness
0.44 in
Dimensions Panel Hole Drill Size
37/64 in
Dimensions T
3/8 in
Dimensions Tx
1/4 in
Specifications Body Material
Brass
Specifications Brand Series
Griplok
Specifications Connection 1 Size
3/8 in
Specifications Connection 1 Type
Tube Fitting
Specifications Connection 2 Size
1/4 in
Specifications Connection 2 Type
Tube Fitting
Specifications End Connections
TF x Tube Fitting
Specifications Handle Color
0
Specifications Handle Type
0
Specifications Production Category
3
Specifications Shape
Straight
Specifications Specialty
Bulkhead
Category 6
Griplok® Tube Fittings
