Griplok Positionable Male Branch Tee SAE - Brass Fitting
Griplok Positionable Male Branch Tee SAE - Brass Fitting
SKU:SSP-40e23e
Upgrade fluid systems with the Griplok Positionable Male Branch Tee SAE fitting for precise installations and secure connections.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Griplok Positionable Male Branch Tee SAE - Brass Fitting
$24.99
Quantity: 1
Claim Your Seller Account
Griplok Positionable Male Branch Tee SAE - Brass Fitting
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Upgrade your fluid systems with the Griplok Positionable Male Branch Tee SAE fitting. Crafted from durable brass, this tee features 3/8-inch tube fittings on both connections and a 9/16-18 Male SAE for secure connections. The innovative design allows for easy positioning, ensuring precise installation. With dimensions of A: 2.52 in, Bx: 0.97 in, C: 0.76 in, D: 0.66 in, E: 0.28 in, G: 11/16 in, H: 5/8 in, T: 3/8 in, Ax: 1.26 in, B: 1.94 in, Hx: 11/16 in, S: 9/16-18, this Griplok tee is reliable and efficient.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Dimensions A
2.52 in
Dimensions Ax
1.26 in
Dimensions B
1.94 in
Dimensions Bx
0.97 in
Dimensions C
0.76 in
Dimensions D
0.66 in
Dimensions E
0.28 in
Dimensions G
11/16 in
Dimensions H
5/8 in
Dimensions Hx
11/16 in
Dimensions S
9/16-18
Dimensions T
3/8 in
Specifications As568 O Ring Uniform Size Number
-906
Specifications Body Material
Brass
Specifications Brand Series
Griplok
Specifications Connection 1 Size
3/8 in
Specifications Connection 1 Type
Tube Fitting
Specifications Connection 2 Size
3/8 in
Specifications Connection 2 Type
Tube Fitting
Specifications Connection 3 Size
3/8 in
Specifications Connection 3 Type
Male SAE
Specifications End Connections
TF x TF x Male SAE
Specifications Handle Color
0
Specifications Handle Type
0
Specifications Production Category
4
Specifications Shape
Tee
Category 6
Griplok® Tube Fittings
