H300 Type Round Outlet Box - Cast Iron, Galvanized, NEMA 3R/IV
H300 Type Round Outlet Box - Cast Iron, Galvanized, NEMA 3R/IV
SKU:H30-50a6e0
Durable cast iron outlet box with NEMA 3R/IV rating, ideal for outdoor installations. Includes stainless steel screws.
Regular price
$29.99
Regular price
Sale price
$29.99
Unit price
per
Initiate Order
H300 Type Round Outlet Box - Cast Iron, Galvanized, NEMA 3R/IV
$29.99
Quantity: 1
Claim Your Seller Account
H300 Type Round Outlet Box - Cast Iron, Galvanized, NEMA 3R/IV
$29.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The H300 Type Round Outlet Box is expertly constructed from durable cast iron with hot-dip galvanization, ensuring corrosion resistance for outdoor installations. This surface-mountable box features a NEMA 3R/IV rating, providing superior protection against the elements. Each unit includes a box, plain cover, gasket, and stainless steel screws for secure installation. The mounting lugs are drilled for 1/4" bolts, with the option for additional drilling and tapping. With a max conduit size of 3/4", outside depth of 3 3/8", and inside depth of 1 1/2", this box is versatile and reliable for various applications.
Product Specifications
Specifications Approx Weight
2.5 lbs
Specifications Construction
cast iron
Specifications Holes Can Be Boss Drilled And Tapped
Holes can be boss, drilled and tapped by Hope Electrical Products at additional cost. Please mark up the hole locations on the attached drilling template and submit with your order to request for quote.
Specifications Inside Depth
1 1/2 in.
Specifications Max Conduit
3/4 in.
Specifications Mounting
Surface
Specifications Outside Depth
3 3/8 in.
Specifications Stock Note
If you donât see a box size listed that you need, please inquire - we may have it. This list does not represent all of our boxes.
Specifications Type
H300
