H300 Type Round Outlet Box - Cast Iron Galvanized Surface Mounting

Name: H300 Type Round Outlet Box - Cast Iron Galvanized Surface Mounting
Brand: Hope Electrical Products Co., Inc.
SKU: H30-e90ece
Price: 24.99 USD
Availability: OutOfStock

SKU:H30-e90ece

Durable H300 Round Outlet Box, Max 1" Conduit, NEMA 3R, Cast Iron, Galvanized, Mounting Lugs

$24.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The H300 Type Round Outlet Box is constructed from durable cast iron with hot dip galvanization for superior corrosion resistance, suitable for outdoor NEMA 3R and NEM IV installations. This unit includes a box, plain cover, gasket, and stainless steel screws. Mounting lugs are drilled for 1/4" bolts, with the option for additional drilling and tapping. Compatible with various pendant covers for expanded functionality. Weighing 3.2 lbs, this outlet box offers a max conduit size of 1 inch and depths of 3 3/8 inches outside and 1 3/4 inches inside.

Product Specifications

Specifications Approx Weight

3.2 lbs

Specifications Construction

cast iron

Specifications Holes Can Be Boss Drilled And Tapped

Holes can be boss, drilled and tapped by Hope Electrical Products at additional cost. Please mark up the hole locations on the attached drilling template and submit with your order to request for quote.

Specifications Inside Depth

1 3/4 in.

Specifications Max Conduit

1 in.

Specifications Mounting

Surface

Specifications Outside Depth

3 3/8 in.

Specifications Stock Note

If you donât see a box size listed that you need, please inquire - we may have it. This list does not represent all of our boxes.

Specifications Type

H300
