H300 Type Round Outlet Boxes - Cast Iron Surface Mounting
H300 Type Round Outlet Boxes - Cast Iron Surface Mounting
SKU:H30-aa7c2e
Durable H300 Type Round Outlet Boxes for NEMA 3R & NEMA IV applications, featuring cast iron construction & surface mounting.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
H300 Type Round Outlet Boxes - Cast Iron Surface Mounting
$39.99
Quantity: 1
Claim Your Seller Account
H300 Type Round Outlet Boxes - Cast Iron Surface Mounting
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The H300 Type Round Outlet Boxes are constructed with durable cast iron and hot-dip galvanized for enhanced protection. Designed for NEMA 3R and NEMA IV applications, each unit includes a box, plain cover, gasket, and stainless steel screws. Mounting lugs are drilled for 1/4" bolt with the option for additional drilling or tapping. These boxes feature an outside depth of 4 3/8 inches and inside depth of 1 3/4 inches, weighing approximately 4.5 lbs. Holes can be boss, drilled, and tapped as per requirements, ensuring flexibility and customization. Compliant with relevant industry standards for institutional procurement.
Product Specifications
Specifications Approx Weight
4.5 lbs
Specifications Construction
cast iron
Specifications Holes Can Be Boss Drilled And Tapped
Holes can be boss, drilled and tapped by Hope Electrical Products at additional cost. Please mark up the hole locations on the attached drilling template and submit with your order to request for quote.
Specifications Inside Depth
1 3/4 in.
Specifications Max Conduit
1 in.
Specifications Mounting
Surface
Specifications Outside Depth
4 3/8 in.
Specifications Stock Note
If you donât see a box size listed that you need, please inquire - we may have it. This list does not represent all of our boxes.
Specifications Type
H300
