Hastelloy C22 Alloy Pipe 8 Inch Schedule 120 Seamless/Welded
Hastelloy C22 Alloy Pipe 8 Inch Schedule 120 Seamless/Welded
SKU:NIC-ace5ae
Cost-effective Hastelloy C22 Alloy Pipe with superior corrosion resistance and ductility, available in various sizes. Ideal for chemical, oil & gas industries.
Regular price
$1,850.00
Regular price
Sale price
$1,850.00
Unit price
per
Initiate Order
Hastelloy C22 Alloy Pipe 8 Inch Schedule 120 Seamless/Welded
$1,850.00
Quantity: 1
Claim Your Seller Account
Hastelloy C22 Alloy Pipe 8 Inch Schedule 120 Seamless/Welded
$1,850.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hastelloy C22 Alloy Pipe, also known as Inconel 22 or Hastelloy C22, is a fully austenitic nickel-based superalloy offering exceptional corrosion resistance and ease of forming. With resistance to various forms of corrosion and stress cracking, this pipe is highly ductile, facilitating cold forming processes. Available in both seamless and welded options from 1/8" up to 26" sizes, it is a cost-effective and versatile choice for industries like chemical processing, oil and gas, and nuclear fuel reprocessing. The chemical composition includes 20-22.5% Cr, 12.5-14.5% Mo, with a melting point between 2020ºF and 2150ºF for annealing treatment.
Product Specifications
Additional Information Additional Information
Common applications include chemical processing, paper and pulp, oil and gas, pesticide production, sour gas services, and waste incinerators. Providing considerable resistance at elevated temperatures, Inconel® 22 has been adopted for nuclear fuel reprocessing, flue gas desulfurization and seawater-based applications.With the nickel as its primary base, Inconel® 22 alloy includes a chemical composition of 20-22.5% Cr, 12.5-14.5% Mo, a maximum of 2.5% Co, 2.5-3.5% W, and 2-6% Fe. For annealing treatment, temperature ranges should remain between 2020 and 2150 ºF. Inconel® 22 is suited for applications that require superior performance at elevated temperatures and for its full spectrum of anti-corrosion characteristics.
Nickel Alloy Compositions Alloy
Alloy C22
Nickel Alloy Compositions Astm Specification
ASME Code Case 2226 | ASME Code Case N-621 | ASME SB 619/SB 775 | ASME SB 622/SB 829 | ASME SB 626/SB 751 | ASTM B 619/B 775 | ASTM B 622/B 829 | ASTM B 626/B 751 | DIN 17751 | ISO 6207
Nickel Alloy Compositions Density
8.69 g/cm³ | 0.314 lbs/in³
Specifications Material
Hastelloy®
Specifications Nominal Diameter Metric
200 mm
Specifications Nominal Diameter Standard
8 inches
Specifications Od
8.625 inches | 219.075 mm
Specifications Shapeform
Pipe
Specifications Thickness
Sch. 120
