Hayward TBH Series PVC True Union Ball Valve - 2-1/2" Socket EPDM
Hayward TBH Series PVC True Union Ball Valve - 2-1/2" Socket EPDM
SKU:TRU-1f5750
Reliable 2-1/2" PVC True Union Ball Valve with EPDM seals for high-pressure applications. ISO 5211 Top Flange, NSF/ANSI 61 & 372 Listed.
Regular price
$189.99
Regular price
Sale price
$189.99
Unit price
per
Initiate Order
Hayward TBH Series PVC True Union Ball Valve - 2-1/2" Socket EPDM
$189.99
Quantity: 1
Claim Your Seller Account
Hayward TBH Series PVC True Union Ball Valve - 2-1/2" Socket EPDM
$189.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Hayward TBH Series PVC True Union Ball Valve in 2-1/2" size features a durable PVC body with EPDM seals, ensuring a reliable seal under high pressure. With a Cv Coefficient of 340, this valve guarantees optimal flow performance, suitable for applications in municipal water treatment, chemical processing, marine systems, and more. Its ISO 5211 Top Flange enables easy actuation, while the lock-out tag out mechanism enhances safety measures. Certified to NSF/ANSI 61 and NSF/ANSI 372 standards, this valve meets stringent industry requirements for quality and safety.
Product Specifications
Key Features And Benefits 0
System2⢠Sealing Technology provides longer cycle life for sizes up to 2"/DN50250 PSI / 16 Bar for sizes 1/2" - 2" / 235psi/16Bar for sizes 2-1/2" - 4", non-shock at 70°F/23°C full pressure ratingConsistent operating torque with adjustment-free designLockout/Tagout mechanism that secures directly to valve body for enhanced safetyErgonomic handle for improved grip and comfortISO mounting flange simplifies actuationPermanent markings, eliminates labelsIntegral footpad for skid or panel mountFPM or EPDM sealsDouble O-Ring stem sealsReversible PTFE seats â standardEasy replacement for existing Hayward TB/CV SeriesNSF/ANSI 61 and NSF/ANSI 372 Listed
Materials 0
PVC per ASTM D1784 Cell Class 12454 CPVC per ASTM D1784 Cell Class 23447 GFPP per ASTM D4101 Cell Class 85580 (Handle & Lock Plate)
Options And Accessories 0
Pneumatic or Electric Actuators Stem Extensions Manual Limit Switch or Spring Return Handle
Sample Specification 0
All 1/4" - 6" thermoplastic ball valves shall be manufactured with PVC Type 1, Grade 1 (ASTM D1784, Cell Classification 12454) or CPVC (ASTM D1784, Cell Classification 23447). All sizes of shall be of true union design. Valve body shall contain an integral top mounting flange with dimensions and bolt circles conforming to ISO 5211. Valve to include as standard sliding lock-out plate that interlocks with integral flange on body for lock-out / tag-out. The valve has four locations for attaching a padlock. Body shall incorporate molded in foot pad for panel or rail mounting. Valves 2" and smaller shall have a floating ball and System2⢠seat carrier design that moves with the seat to affect a double seal to flow through a closed valve, and require no adjustment. Sizes 2-1/2â through 6â shall have energized PTFE seats with backing O-ring as standard. All seats for shall be reversible to allow field rebuild. Seats shall be PTFE as standard. All O-rings shall be EPDM or FPM. The handle shall be retained without any metal fasteners and made from GFPP with UV Inhibitor. Balls must be full-port design and fully sphere shape. Stem shall contain double O-rings, and shall be blowout proof design. Valve stem design shall be such that any torsional failure occurs outside of the two stem O-rings. All 1/4" - 2" ball valves shall be pressure-rated for 250 PSI at 70°F non-shock. Sizes 2-1/2â â 4â valves shall be pressure rated for 235psi at 70°F non-shock. All sizes of ANSI 150 lb. flanged ball valves shall be pressure-rated for 150 PSI at 70°F non-shock. All PVC and CPVC valves to be NSF/ANSI 61 and NSF/ANSI 372 Listed. All ball valves shall carry a Global 3- Year warranty, and shall be manufactured by Hayward® Flow Control and in the USA.
Specifications Cv Coefficient
340
Specifications End Connection
Socket
Specifications Flow Configuration
Bi-directional
Specifications Handle Material
GFPP
Specifications Operating Pressure Max
16 bar | 235 psi
Specifications O Ring Material
EPDM
Specifications Seat Material
PTFE
Specifications Series
TBH
Specifications Size
2-1/2"
Specifications Valve Material
PVC
Specifications Weight
5.13 kg | 11.30 lb
Applications 0
Typical applications or installations include but are not limited to municipal waste and water treatment, clean water technology, chemical transfer and processing, aquatic and animal life support systems, mining and mineral processing, metal plating / surface finishing, marine, pulp and paper, landfills / environmental infrastructure and other demanding applications.
