HDPE Bore Duct - ASTM D3035 SDR 11 - 5" Nominal OD

Name: HDPE Bore Duct - ASTM D3035 SDR 11 - 5" Nominal OD
Brand: Colonial Teltek
SKU: PVC-a55832
Price: 49.99 USD
Availability: OutOfStock

SKU:PVC-a55832

Premium HDPE Bore Duct - ASTM D3035 compliant, smoothwall design, high strength & OD control for directional boring projects.

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The HDPE Bore Duct, compliant with ASTM D3035 standards, features a smoothwall design manufactured from premium high-density polyethylene resin. With high tensile strength, crush resistance, and precise OD control, this OD bore duct is ideal for directional boring projects. It offers a balance of toughness, flexibility, and low friction, meeting industry standards for fiber optic innerducts. Available in black or orange, with optional rope/tape and custom reel sizes, this duct ensures reliability and durability in underground installations.

Product Specifications

Specifications Min Wall In

0.506

Specifications Min Wall Mm

12.9

Specifications Nominal Id In

4.491

Specifications Nominal Id Mm

114.1

Specifications Nominal Od In

5.563

Specifications Nominal Od Mm

141.3

Specifications Sdr

Specifications Size In

Specifications Size Mm

127.0

HDPE Bore Duct - ASTM D3035 SDR 11 - 5" Nominal OD
