HDPE Bore Duct - ASTM D3035 SDR 13.5 - 5" OD

Name: HDPE Bore Duct - ASTM D3035 SDR 13.5 - 5" OD
Brand: Colonial Teltek
SKU: PVC-c1ccef
Price: 49.99 USD
Availability: OutOfStock

SKU:PVC-c1ccef

Premium HDPE Bore Duct - ASTM D3035 SDR 13.5 - 5" OD for fiber optic innerducts.

$49.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The HDPE Bore Duct, compliant with ASTM D3035 standards, is designed for directional boring projects, offering a smoothwall construction from premium HDPE resin. With high tensile strength, maximum crush resistance, and precise sizing (5" OD, 4.689" ID), this bore duct ensures durability, flexibility, and low friction coefficient, essential for fiber optic innerduct installations. UV stabilized for outdoor use, it meets rigorous Plastic Pipe Institute criteria, making it an ideal choice for demanding applications.

Product Specifications

Specifications Min Wall In

0.412

Specifications Min Wall Mm

10.5

Specifications Nominal Id In

4.689

Specifications Nominal Id Mm

119.1

Specifications Nominal Od In

5.563

Specifications Nominal Od Mm

141.3

Specifications Sdr

13.5

Specifications Size In

Specifications Size Mm

127.0

HDPE Bore Duct - ASTM D3035 SDR 13.5 - 5" OD
