Heat-Resistant Glass Epoxy Rod
Heat-Resistant Glass Epoxy Rod
SKU:SHA-3ef63a
High-performance NEMA G-11 Glass Epoxy Rod ground from premium sheet material. Meets MIL-I-24768/28 GEB-F. Exceptional strength & thermal stability.
Regular price
$39.99
Regular price
Sale price
$39.99
Unit price
per
Initiate Order
Heat-Resistant Glass Epoxy Rod
$39.99
Quantity: 1
Claim Your Seller Account
Heat-Resistant Glass Epoxy Rod
$39.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
Our NEMA G-11 Glass Epoxy Rod, ground from premium sheet material, meets stringent MIL-I-24768/28 GEB-F standards. Crafted with woven fiberglass cloth and epoxy resin, this thermoset composite offers exceptional mechanical strength, thermal stability, and electrical properties. With a Rockwell Hardness of M110 and a maximum operating temperature of 400°F, this rod is ideal for demanding mechanical and electrical applications. Its high tensile, flexural, and compressive strength, coupled with excellent machinability, make it a reliable choice for various industrial needs.
Product Specifications
Specifications Coefficient Of Thermal Expansion Crosswise
0.83 x 10-5 in/in/ºF
Specifications Coefficient Of Thermal Expansion Lengthwise
0.72 x 10-5 in/in/ºF
Specifications Compressive Strength
75000 psi
Specifications Density Astm D792
1.85 g/cm³
Specifications Dielectric Strength Short Time 0125 Astm D149
530 V/mil
Specifications Flammability Rating Ul 94
HB
Specifications Flexural Modulus Crosswise Astm D790
15 x 105 psi
Specifications Flexural Modulus Lengthwise Astm D790
17 x 105 psi
Specifications Flexural Strength Crosswise Astm D790
62000 psi
Specifications Flexural Strength Lengthwise Astm D790
70000 psi
Specifications Hardness Rockwell Astm D785
M110
Specifications Izod Impact Strength Notched Crosswise Astm D256
10 ft·lb/in
Specifications Izod Impact Strength Notched Lengthwise Astm D256
13 ft·lb/in
Specifications Length
4 ft
Specifications Maximum Operating Temperature
400 ºF
Specifications Tensile Strength Crosswise Astm D638
44000 psi
Specifications Tensile Strength Lengthwise Astm D638
48000 psi
Specifications Tolerance
± 0.001 in
Specifications Water Absorption 24 Hrs At 0125 Astm D570
0.15 %
