Heavy Duty Electric Hoist E4 - 6000 lbs Capacity, 60 FPM
Heavy Duty Electric Hoist E4 - 6000 lbs Capacity, 60 FPM
SKU:RIG-ca3af9
High-performance Heavy Duty Electric Hoist E4 designed for efficient, safe, and rugged hoisting applications.
Regular price
$3,999.99
Regular price
Sale price
$3,999.99
Unit price
per
Initiate Order
Heavy Duty Electric Hoist E4 - 6000 lbs Capacity, 60 FPM
$3,999.99
Quantity: 1
Claim Your Seller Account
Heavy Duty Electric Hoist E4 - 6000 lbs Capacity, 60 FPM
$3,999.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Model E4 Heavy Duty Hoists are precision-engineered for high-speed hoisting applications with a 6000 lbs running capacity. Featuring an 8 3/4" drum diameter, 20 HP motor, and automatic mechanical load holding safety brake, this hoist ensures efficient and safe lifting operations. With optional equipment like electric motor brake and multiple wire ropes off the drum, it meets the most rigorous industrial standards, making it ideal for heavy-duty use in various settings.
Product Specifications
Specifications Controls
Lever Drum Mounted at Winch | Magnetic Remote Pushbutton
Specifications Drum 3 Layers
350 ft.
Specifications Drum Diameter
8 3/4 inches
Specifications Electrical Current
230/460-3-60
Specifications Full Drum
815 ft.
Specifications Line Speed
60 FPM
Specifications Motor
20 HP
Specifications Mounting
Horizontal Base | Inverted Ceiling | Vertical
Specifications Net Weight
980 lbs.
Specifications Optional Equipment
Controls to suit application | Grooved drums | Overspeed automatic load holding drum brake and electric shut-off | Electric Motor Brake (recommended for all hoisting applications) | Two or more wire ropes off the drum | Slack Line Limit Switch | Travel Limit Switch | Cable Drum Pressure Roller - assists multiple layer reeving evenly onto drum | Mechanical Torque Limiter - automatic reset
Specifications Running Capacity Lbs
6000
Specifications Standard Wire Rope Diameter
1/2 inches
Specifications Winch Height
23 inches
Specifications Winch Length
61 inches
Specifications Winch Width
27 inches
Specifications Winch Will Be Used For
Electrical Brake Required | Lifting | Pulling
Standard Features 0
Ideal for long lift high speed hoisting applications Drum large diameter increases wire rope life Precision gearing self-locking reduction oil bath lubricated Safety brake automatic mechanical load holding type Regenerative lowering electrically retarded lowering speed Totally enclosed motor high torque hoist duty motor starting capacity is minimum two (2) times running All weather use is ideal for rugged model E4 winches minimum 5 to 1structural safety factor
